Global OBDII Diagnostics
4
Scan tool displays a NO RECORDING PRESENT message if recording does
not exist. Otherwise, press
ENTER to play back recording. Scan tool plays back
Entire Data List or Custom Data List, depending on how data was recorded.
The Playback has three lines of data
and one line for frame number and
timestamp (in seconds).
Negative frames and timestamps indicate data recorded before trigger event.
Positive frames and timestamps indicate data recorded after trigger event.
Use
UP/DOWN arrow keys to view recorded PID data of each frame. The end
of list is reached when only
] (up) icon is visible.
Use
LEFT/RIGHT arrow keys to scroll back and forth through frames. The
RIGHT arrow key goes to next frame, “wrapping around” to earliest frame when
final frame is reached,
LEFT arrow key goes back to previous frame, again
“wrapping around” to final frame.
✓ Different vehicles communicate at different speeds and support a different
number of PIDs. Therefore, maximum number of frames that can be
recorded will vary.
✓ Some vehicles wait a long period of time to store a trouble code after
driveability problem occurs. If operator selected “Trigger On Codes” when
making recording, operator might not see any drastic change in data
parameters before and after trigger point. In cases like this, user can
manually trigger recording when symptoms are observed.
When done, press
BACK to return to Review Data or OBDII Function List.
MIL STATUS($10) ON
MIL STATUS($1A) ON
ABSLT TPS(%)($10) 35[
FRAME: 1 TM: 4.4
~
