64 4 Tool Management
4.1 Tool Table
Clearing an entire line of tool data
All data pertaining to a tool number can be removed at once.
Select the tool number.
Touch the Next Menu button in the lower tool bar.
Touch the Clear Line button to remove all data.
Clearing the current tool table
All data pertaining to a tool number can be removed at once.
Touch the Next Menu button in the lower tool bar.
Touch the Clear Table button to remove all data.
