The PXELINUX and gPXE environments allow your target machine to boot the ESXi installer. PXELINUX is
part of the SYSLINUX package, which can be found at
http://www.kernel.org/pub/linux/utils/boot/syslinux/, although many Linux distributions include it. Many
versions of PXELINUX also include gPXE. Some distributions, such as Red Hat Enterprise Linux version 5.3,
include earlier versions of PXELINUX that do not include gPXE.
If you do not use gPXE, you might experience problems while booting the ESXi installer on a heavily loaded
network TFTP is sometimes unreliable for transferring large amounts of data. If you use PXELINUX without
gPXE, the pxelinux.0 binary file, the configuration file, the kernel, and other files are transferred by TFTP. If
you use gPXE, only the gpxelinux.0 binary file and configuration file are transferred by TFTP. With gPXE,
you can use a Web server to transfer the kernel and other files required to boot the ESXi installer.
NOTE VMware tests PXE booting with PXELINUX version 3.86. This is not a statement of limited support.
For support of third-party agents that you use to set up your PXE booting infrastructure, contact the vendor.
Figure 7‑1. Overview of PXE Boot Installation Process
DHCP server
DHCP server
Web server
ESXi target host
ESXi host
Give me an IP
for the virtual
network adapter
UDP
IP & TFTP server
kernel
IP
TCP for gPXELINUX
UDP for PXELINUX
UDP
Give me
the kernel
Give me an IP
for the kernel
TFTP server
gpxelinux.0 or pxelinux.0
UDP
Give me the
network boot loader
scripts depot
Installer
starts
ks.cfg
TCP
Give me an
installation script
