M-322 ATX Industrial Motherboard with Intel® Q35 Chipset User’s Manual Manual Rev.: 2.01 Revision Date: September 27, 2010 Part No: 50-1Z052-1010 Advance Technologies; Automate the World.
Revision History Revision Release Date Description of Change(s) 2.00 2010/06/23 Initial Release 2.
M-322 Preface Copyright 2010 ADLINK Technology Inc. This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer. Disclaimer The information in this document is subject to change without prior notice in order to improve reliability, design, and function and does not represent a commitment on the part of the manufacturer.
Using this Manual Audience and Scope The M-322 User’s Manual is intended for hardware technicians and systems operators with knowledge of installing, configuring and operating industrial grade computers. Manual Organization This manual is organized as follows: Preface: Presents copyright notifications, disclaimers, trademarks, and associated information on the proper usage of this document and its associated product(s).
M-322 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: CAUTION: WARNING: Preface Information to prevent minor physical injury, component damage, data loss, and/or program corruption when trying to complete a task.
This page intentionally left blank.
M-322 Table of Contents Revision History...................................................................... ii Preface .................................................................................... iii List of Figures ........................................................................ xi List of Tables........................................................................ xiii 1 Introduction ........................................................................ 1 1.1 Package Contents ....
4 BIOS Setup ........................................................................ 37 4.1 Starting the BIOS ............................................................... 37 4.2 Main Setup......................................................................... 41 4.3 Advanced Setings .............................................................. 45 4.3.1 USB Configuration ......................................................... 46 4.3.2 Trusted Computing ..........................................
M-322 Important Safety Instructions .............................................. 77 Getting Service......................................................................
This page intentionally left blank.
M-322 List of Figures Figure 1-1: Figure 1-2: Figure 1-3: Figure 1-4: Figure 1-5: M-322 Block Diagram ...................................................... 6 M-322 Board Layout ........................................................ 9 M-322 Rear I/O Layout .................................................. 10 M-322 Board Dimensions .............................................. 11 M-322 I/O Shield Dimensions ........................................
This page intentionally left blank.
M-322 List of Tables Table Table Table Table Table Table Table Table Table Table Table 1-1: 1-2: 2-1: B-1: B-2: B-3: B-4: B-5: B-6: B-7: B-8: List of Tables M-322 General Specifications.......................................... 4 M-322 Board Layout Legend ......................................... 10 COM Serial Port Connector Pin Definition..................... 14 System Memory Map..................................................... 67 Direct Memory Access Channels...................................
This page intentionally left blank.
M-322 1 Introduction This chapter will introduce the M-322, its features, specifications, functional description, and mechanical layout. 1.1 Package Contents Please check that your package contains the items below. If you discover damaged or missing items, please contact your vendor.
1.2 Overview The ADLINK M-322 is an ATX industrial motherboard supporting the next-generation Intel® Core™2 Quad/Duo, Pentium® Dual Core and Celeron® processors in the LGA775 package to deliver a high performance platform for a wide array of industrial applications. The M-322 supports processing speeds up to 3.00GHz and 1333 MHz Front Side Bus (FSB). Dual channel DDR2 667/800 MHz memory is supported up to a maximum of 8GB in four DIMM slots.
M-322 1.4 Specifications System CPU/Cache • IIntel® Core™2 Quad Q9400, 2.66GHz, 1333MHz FSB, 6MB L2 Cache, 45nm, 95W TDP • Intel® Core™2 Duo E8400, 3.0GHz, 1333MHz FSB, 6MB L2 Cache, 45nm, 65W TDP • Intel® Core™2 Duo E7400, 2.8GHz, 1066MHz FSB, 3MB L2 Cache, 45nm, 65W TDP • Intel® Core™2 Duo E6400, 2.13GHz, 1066MHz FSB, 2MB L2 Cache, 65nm, 65W TDP • Intel® Core™2 Duo E4300, 1.8GHz, 800MHz FSB, 2MB L2 Cache, 65nm, 65W TDP • Intel® Pentium® Dual Core E5300, 2.
I/O Interfaces Serial ATA • 6x Serial ATA ports with 300 MB/s data transfer • Supports RAID 0/1/5/10 Onboard I/O • • • • • • 4x USB 2.0 pin headers (8 ports) 2x RS-232 serial port pin headers (COM2-3) 1x RS-232/422/485 serial port (COM4) 1 printer port 1x floppy port 1x front panel pin header Rear I/O • • • • • • 2x RJ-45 LAN port 4x USB 2.
M-322 1.5 Power Consumption Intel® Core™2 Duo Processor E6400 Test Configuration CPU Intel® Core™2 Duo Processor E6400 2.13 GHz Memory ADATA DDR2 667 1G (AD2667001GOU) x1 Graphics Intel ® Q35 Graphics Memory Controller Hub Hard Drive Seagate Barracuda 7200.10 160GB ST3160815AS Power Supply Delta 400W, GPS-400AB C Rev. 00F Power On Boot Sequence Power Req. +5V +3.3V +12V 5VSB Total Current 2.12 A 2.14 A 2.84 A 0.62 A — Power — — — — 54.84 W Power Req. +5V +3.
1.6 Block Diagram CPU Core™2 Quad/Duo Pentium® Dual Core Celeron® LGA775 package 800/1066/1333 MHz FSB Northbridge CRT DB-15 Channel A DDR2 667/800 MHz PCIe x16 slot 4x DIMM Intel® Q35 GMCH Channel B DMI Interface 2 GB/s Southbridge Intel® ICH9DO PCIe x1 2x RTL8111C PCIe GbE PCIe x1 PCI Express x1 JMicron JMB368 PCIe to PATA controller PCIe Controller SATA 6x SATA ports 12x USB 2.0 (4x Bracket, 8x Internal) USB 2.
M-322 1.7 Functional Description Processor Support The M-322 is designed for Intel Yorkfield/Wolfdale/Conroe quad, dual and single core processors in LGA775 socket with core frequencies from 1.8 GHz up to 3.0 GHz. The CPU connects with the Intel® Q35 GMCH through a 2 GB/s DMI interface. Intel® Q35 Express Chipset The Intel® Q35 Express chipset (Q35 GMHC + ICH9DO) provides the vital interfaces for the SHB.
Gigabit Ethernet The M-322 uses two Realtek RTL8111C Gigabit Ethernet controllers connected to the PCI-E x1 bus of the ICH9DO. Operation at data rates of 10/100/1000 Mbps, Wake on LAN are supported. Serial ATA Storage is efficient and secure with the Serial ATA interface. Utilizing the Intel® ICH9DO, the M-322 supports up to six Serial ATA devices capable of reading/writing data at up to 3 Gbps. Intel® Matrix Storage Technology provides support for RAID 0/1/5/10.
M-322 1.
AAFP Front Panel Audio Connector ATX12V ATX Power Connector CD-IN Optical Drive Audio Connector CHA_FAN1 Chassis Fan Connector CHASSIS Chassis Intrusion Connector CLRTC Clear CMOS Jumper COM2-4 Serial Port Connector 2-4 CPU_FAN CPU Fan Connector EATXPWR ATX Power Connector FLOPPY Floppy Disk Drive Connector F_PANEL System Panel Pin Header JAMP1 Amplified Audio Pin Header JCOMPWR1-4 COM1-4 RI, +12V and +5V Select Jumpers JCOMPWR5-7 COM4 RS-232/422/485 Select Jumpers JDIO Digital
M-322 1.
Dimensions in mm Figure 1-5: M-322 I/O Shield Dimensions 12 Introduction
M-322 2 Connectors & Jumpers The connectors and jumpers on the M-322 allow you to connect and configure external devices. The following specify the pin assignments for connectors and jumper on the M-322. Refer to Figure 1-2: M-322 Board Layout and Figure 1-3: M-322 Rear I/O Layout for connector and jumper locations. 2.
COM DB-9 Serial Port Connector Pin # RS-232 1 DCD, Data carrier detect 2 RXD, Receive data 3 TXD, Transmit data 4 DTR, Data terminal ready 5 GND, ground 6 DSR, Data set ready 7 RTS, Request to send 8 CTS, Clear to send 9 RI, Ring indicator Table 2-1: COM Serial Port Connector Pin Definition VGA Connector.
M-322 Parallel Port.
LAN (RJ-45) Ports Pin # 10BASE-T/ 100BASE-TX 1000BASE-T 1 TX+ BI_DA+ 2 TX- BI_DA- 3 RX+ BI_DB+ 4 -- BI_DC+ 5 -- BI_DC- 6 RX- BI_DB- 7 -- BI_DD+ 8 -- BI_DD- LED1 8 LED2 1 Refer to the table below for the LAN port LED definitions.
M-322 2.2 Onboard Connectors Front Panel Audio Pin Header (AAFP) Pin # Signal Pin # Signal 1 MIC2_L 6 AGND 2 MIC2_R 7 FP_PRES# 3 MIC2_R 8 SRTN1 4 SENSE A 9 Key 5 LIN2_L 10 SRTN2 1 6 ATX 12V Power Connector (ATX12V) Pin # Signal 1 GND 2 GND 3 +12V DC 4 +12V DC 2 1 4 3 ATX Power Connector (EATXPWR) Pin # Signal Pin # Signal 1 +3.3V 13 +3.3V 2 +3.
CD-in Connector (CD) Pin # Signal 1 Left Audio Channel 2 CD_GND 3 CD_GND 4 Right Audio Channel 1 System Fan Connector (CHA_FAN1) Pin # Signal 1 Fan Sense 2 Fan Power (+12V) 3 GND 1 3 CPU Fan Connector (CPU_FAN) Pin # Signal 1 GND 2 Fan Power (+12V) 3 Fan Sense 4 Fan Speed Control 4 1 Chassis Intrusion Connector (CHASSIS) Pin # Signal 1 +5Vsb 2 – 3 Chassis Signal 4 GND 1 Note: Short pins 3 and 4 if not connected to chassis.
M-322 Serial Port Connectors RS-232 (COM2-4) Pin # RS-232 1 DCD, Data carrier detect 2 RXD, Receive data 3 TXD, Transmit data 4 DTR, Data terminal ready 5 GND, ground 6 DSR, Data set ready 7 RTS, Request to send 8 CTS, Clear to send 9 RI, Ring indicator 1 2 9 Serial Port Connectors RS-422/485 (COM4) Pin # RS-422 RS-485 1 TXD- TXD- 2 TXD+ TXD+ 3 RXD- NC 4 RXD+ NC 5 NC NC 6 NC NC 7 NC NC 8 NC NC 9 NC NC See “COM4 RS-242/422/485 Select (JCOMPWR5, 6, 7)” on
Floppy Disk Drive Connector (FLOPPY) Pin # Signal Pin # Signal 1 GND 2 Extended Density 3 GND 4 NC 5 NC 6 NC 7 GND 8 Index 9 GND 10 Motor A Select 11 GND 12 NC 13 GND 14 Drive A Select 15 GND 16 NC 17 GND 18 Step Direction 19 GND 20 Step Pulse 21 GND 22 Write Data 23 GND 24 Write Gate 25 GND 26 Track 0 27 GND 28 Write Protect 29 GND 30 Read Data 31 GND 32 Head Select 33 GND 34 Disk Change System Panel Pin Header (F_PANEL) 20 Pin # Si
M-322 Amplifier Audio Pin Header (JAMP1) Pin # Signal 1 AMP_L- 2 AMP_L+ 3 AMP_R- 4 AMP_R+ 1 Digital IO Pin Header (JDIO) Pin # Signal Pin # Signal 1 DIO GP20 2 DIO GP10 3 DIO GP21 4 DIO GP11 5 DIO GP22 6 DIO GP12 7 DIO GP23 8 DIO GP13 9 DIO GP24 10 DIO GP14 11 DIO GP25 12 DIO GP15 13 DIO GP26 14 DIO GP16 15 DIO GP27 16 DIO GP17 17 SMLINK0 18 SMLINK1 19 Ground 20 +5V Connectors & Jumpers 1 2 21
IDE Connector (PRI_EIDE) Pin # Signal Pin # Signal 1 Reset 2 Ground 3 Data 7 4 Data 8 5 Data 6 6 Data 9 7 Data 5 8 Data 10 9 Data 4 10 Data 11 11 Data 3 12 Data 12 13 Data 2 14 Data 13 15 Data 1 16 Data 14 17 Data 0 18 Data 15 19 Ground 20 - 21 Request 22 Ground 23 I/O Write 24 Ground 25 I/O Read 26 Ground 27 I/O Ready 28 Cable Select 29 DMA Ack 30 Ground 31 Interrupt Request 32 No Connect 33 Device Address 1 34 ATA 66/100 Detect 35 De
M-322 SATA Connectors (SATA1-6) Pin # Signal 1 GND 2 TXP 3 TXN 4 GND 5 RXN 6 RXP 7 GND 1 7 S/PDIF Pin Header (SPDIF_OUT) Pin # Signal 1 +5V 2 – 3 SPDIF0 4 GND 1 SPI Pin Header (SPI) Pin # Signal Pin # Signal 1 +3V ROM 2 GND 3 F_SPI_CS# 4 F_SPI_CLK 5 F_SPI_MISO 6 F_SPI_MOSI 7 NC 8 – 1 USB Pin Headers (USB56/78/910/1112) Pin # Signal Pin # Signal 1 +5V 2 +5V 3 USB0- 4 USB1- 5 USB0+ 6 USB01+ 7 GND 8 GND 9 Key 10 – Connectors & Jumpers
2.3 Jumpers Clear CMOS Jumper (CLRTC) The CMOS RAM data contains the date/time and BIOS setting information. CMOS is powered by the onboard button cell battery. To erase the CMOS RAM data: 1. Disconnect power from the M-322 2. Short the CLRTC pins 2-3 3. Turn the power on. After power on, remove the jumper cap from pins 2-3 and reinstall it to pins 1-2. Normal (default) Clear CMOS COM1-4 RI, +12V and +5V Select (JCOMPWR1-4) These jumpers allows you to select RI, +5V and +12V power settings for COM1-4.
M-322 COM4 RS-242/422/485 Select (JCOMPWR5, 6, 7) Short the jumper pins according to the following settings to set COM4 to RS-232/422/485/485 mode.
This page intentionally left blank.
M-322 3 Getting Started This chapter provides information on how to install components to the M-322 motherboard. 3.1 Installing the CPU The M-322 Supports the Intel® Core™2 Duo/Quad, Intel® Pentium® Dual-Core, and Intel® Celeron® processors via the surface mount LGA775 socket (Socket T). WARNING: Disconnect all power supply to the board before installing a CPU to prevent damaging the board and CPU. Do not touch socket contacts. Damaging the contacts voids the product warranty.
2. Lift and rotate the load lever to a 135° angle 3. Lift the load plate to a 100° angle using your thumb and forefinger 4.
M-322 5. Position the CPU over the socket, then match the notches on the CPU side with the alignment keys on the socket. The golden triangle on the CPU must be positioned on the bottom-left corner of the socket . Notch Golden Triangle Alignment Key The CPU fits the socket in only one orientation. DO NOT force it into the socket to avoid damaging it. WARNING: 6. Carefully place the CPU on the socket in a vertical motion. The socket has tabs that accommodate your fingers during installation .
7. Close the load plate (A), then fasten the load lever on the retention tab (B) .
M-322 3.2 Installing the CPU Fan and Heatsink CAUTION: The CPU requires a chassis with an airflow inlet and maximum internal ambient temperature of 60° C. A specially-designed CPU fan and heatsink must be installed before using the motherboard. Failure to install a CPU fan and heatsink may damage the motherboard and/or the CPU. The following CPU fan and heatsink assembly is recommended for use with the M-322: Copper-Core Cooler Dimensions: 115 x 115 x 61.
3.3 System Memory The M-322 supports up to 8 GB of DDR2 667/800 MHz memory modules in four DIMM sockets. DDR2 modules are notched to facilitate correct installation in the DIMM sockets. See Figure 1-2 on page 9 for DIMM socket locations.
M-322 To install a memory module: 1. Locate the DIMM slots on the motherboard. 2. Press the socket’s retaining clips outward to unlock. 3. Align the memory module on the socket making sure that the notch matches the break on the socket. Notch Break 4. Insert the module firmly into the slot until the retaining clips snap back inwards and the module is securely seated.
3.4 Driver Installation This section provides information on how to install the M-322 device drivers under Windows XP. The device drivers are located in the following directories on the driver CD, or can be downloaded from the ADLINK website (http://www.adlinktech.
M-322 Intel® Q35 Express Chipset Driver This section describes the installation of the Intel® Q35 Express chipset driver. 1. Locate the directory X:\Drv_Chipset_Q35\. 2. Run the program setup.exe and follow the onscreen instructions. Restart the system if prompted. Display Driver Follow these instructions to install the display driver: 1. Locate the directory X:\Drv_VGA_GMA3100\ on the driver CD and select the correct operating system. 2. Run the program setup.exe and follow the onscreen instructions.
Intel® Matrix Storage Manager Follow these instructions to install the Intel® Matrix Storage Manager utility. 1. Locate the directory X:\Intel Matrix Storage Manager\ on the driver CD. 2. Run the program iata78_enu.exe and follow the onscreen instructions. Restart the system if prompted. TPM Driver Follow these instructions to install the TPM driver. 1. Locate the directory X:\TPM\ on the driver CD. 2. Run the program setup.exe and follow the onscreen instructions. Restart the system if prompted.
M-322 4 BIOS Setup The following chapter describes basic navigation for the AMIBIOS®8 BIOS setup utility. 4.1 Starting the BIOS To enter the setup screen, follow these steps: 1. Power on the motherboard 2. Press the < Delete > key on your keyboard when you see the following text prompt: < Press DEL to run Setup > 3. After you press the < Delete > key, the main BIOS setup menu displays. You can access the other setup screens from the main BIOS setup menu, such as Chipset and Power menus.
Setup Menu The main BIOS setup menu is the first screen that you can navigate. Each main BIOS setup menu option is described in this user’s guide. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured. “Grayed” options cannot be configured, “Blue” options can be. The right frame displays the key legend. Above the key legend is an area reserved for a text message. When an option is selected in the left frame, it is highlighted in white.
M-322 Note: There is a hot key legend located in the right frame on most setup screens. The < F8 > key on your keyboard is the Fail-Safe key. It is not displayed on the key legend by default. To set the Fail-Safe settings of the BIOS, press the < F8 > key on your keyboard. It is located on the upper row of a standard 101 keyboard. The Fail-Safe settings allow the motherboard to boot up with the least amount of options set. This can lessen the probability of conflicting settings.
F10 The < F10 > key allows you to save any changes you have made and exit Setup. Press the < F10 > key to save your changes. The following screen will appear: Press the < Enter > key to save the configuration and exit. You can also use the < Arrow > key to select Cancel and then press the < Enter > key to abort this function and return to the previous screen. ESC The < Esc > key allows you to discard any changes you have made and exit the Setup.
M-322 4.2 Main Setup When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section. The Main BIOS Setup screen is shown below. System Time/System Date Use this option to change the system time and date. Highlight System Time or System Date using the < Arrow > keys. Enter new values using the keyboard.
Floppy A Sets the type of floppy drive installed. Options: [Disabled], [360KB, 5 1/4], [1.2MB, 5 1/4], [720KB, 5 1/ 4], [1.44MB, 5 1/4], [2.88MB, 3 1/2] SATA 1~6 The BIOS automatically detects the presence of SATA devices. There is a separate sub-menu for each IDE device. Select a device item then press to display the SATA device information and adjust user configurable parameters.
M-322 SATA Configuration SATA Configuration Allows you to disable or enable SATA Configuration function. Options: [Disabled], [Compatible], [Enhanced] Configure SATA as Configures the Serial ATA connectors supported by the Southbridge chip. The AHCI allows the onboard storage drive to enable advanced Serial ATA features that increases storage performance on random workloads by allowing the drive to internally optimize the order of commands.
AHCI Settings System Information 44 BIOS Setup
M-322 4.3 Advanced Setings Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen to go to the sub menu for that item. The sub menus are described on the following pages.
4.3.1 USB Configuration You can use this screen to select options for the USB Configuration. Select an item then press to display the configuration options. USB Functions Allows you to enable or disable USB functions. Options: [Disabled], [Enabled] Legacy USB Support [Enabled] Allows you to enable or disable support for USB devices on legacy operating systems (OS). Setting to Auto allows the system to detect the presence of USB devices at startup.
M-322 USB 2.0 Controller Allows you to enable or disable the USB 2.0 controller. Options: [Enabled], [Disabled]. BIOS EHCI Hand-Off Allow you to enable support for operating systems without an EHCI hand-off feature. Options: [Disabled], [Enabled]. Port 64/60 Emulation Allows you to disable or enable the I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non-USB aware OS.
4.3.2 Trusted Computing Trusted computing is an industry standard to make personal computers more secure through a dedicated hardware chip, called a Trusted Platform Module (TPM). This option enables or disables the TPM support.
M-322 4.3.3 Intel TXT Configuration Allows you to enable or disable Intel® Trusted Execution Technology initialization. Options: [Disabled], [Enabled] 4.3.4 Intel VT-d Configuration Allows you to enable or disable Intel® Virtualization Technology.
4.3.5 CPU Configuration You can use this screen to select options for the CPU Configuration Settings. Hardware Prefetcher Options: [Enabled], [Disabled]. Adjacent Cache Line Prefetch Options: [Enabled], [Disabled]. Max CPUID Value Limit Setting this item to [Enabled] allows legacy operating systems without support for CPUs with extended CPUID functions to boot. Options: [Disabled], [Enabled]. Intel Virtualization Tech Options: [Enabled], [Disabled].
M-322 Execute Disable Bit Allows you to enable or disable the No-Execution Page Protection Technology. Setting this item to [Disabled] forces the XD feature flag to always return a zero (0). Options: [Enabled], [Disabled]. Intel SpeedStep Tech Options: [Enabled], [Disabled].
4.3.6 Chipset Settings The Chipset menu allows you to change the advanced chipset settings. Select an item then press to display the sub-menu. North Bridge Configuration Memory Remap Feature Allows you to enable or disable the remapping of the overlapped PCI memory above the total physical memory. Enable this option only when you install a 64-bit operating system. Options: [Disabled], [Enabled].
M-322 Internal Graphic Mode Select Allows you to select the amount of system memory used by the Internal Graphics Device. Options: [Disabled], [Enabled,1MB], [Enabled, 8MB] PEG Port Control Allows you to disable or enable PEG port control.
4.3.7 Onboard Device Configuration Onboard LAN Boot Options: [Enabled], [Disabled] JMicron 36X ATA Controller Allows you to enable or disable the JMicron 36X ATA controller (PATA function). Options: [Enabled], [Disabled]. Serial Port Address Allow you to select the Serial Port base address. Options: [Disabled], [3F8], [2F8], [3E8], [2E8] Serial Port IRQ Options: [3], [4], [10], [11] Parallel Port Address Allow you to select the Parallel Port base address.
M-322 Parallel Port Mode Allow you to select the Parallel Port mode. Options: [Normal], [Bi-Directional], [ECP], [EPP], [ECP&EPP] Parallel Port IRQ Options: [IRQ5], [IRQ7] 4.3.8 PCI/PnP Settings When set to [No], BIOS configures all the devices in the system. When set to [Yes] and if you install a Plug and Play operating system, the operating system configures the Plug and Play devices not required for boot.
4.4 Power Settings The Power menu items allow you to change the settings for the Power Management. Select an item then press to display the configuration options. Suspend Mode Allows you to select the Advanced Configuration and Power Interface (ACPI) state to be used for system suspend. Options: [S1 (POS)], [S3 (STR)], [Auto] Repost Video on S3 Resume Determine whether to invoke VGA BIOS post on S3/STR Resume.
M-322 ACPI Version Features Allows you to add more tables for Advanced Configuration and Power Interface (ACPI) 2.0 specifications. Options: [ACPI V1.0], [ACPI V2.0], [ACPI V3.0] ACPI APIC Support [Enabled] Allows you to enable or disable the Advanced Configuration and Power Interface (ACPI) support in the Application-Specific Integrated Circuit (ASIC). When set to Enabled, the ACPI APIC table pointer is included in the RSDT pointer list.
4.4.1 APM Configuration Restore on AC Power Loss Determines which state the computer enters when AC power is restored after a power loss. The options for this value are Last State, Power On and Power Off. X Power Off: Set this value to always power off the system while AC power is restored. X Power On: Set this value to always power on the system while AC power is restored. X Last State: Set this value to power off/on the system depending on the last system power state while AC power is restored.
M-322 4.4.2 Hardware Health Configuration This submenu displays system health information (temperatures, voltages, fan speeds) and allows CPU Smart Fan Profile configuration. CPU Smart Fan Profile Allows you to select the CPU FAN profile mode. X Silent Mode: Keeps system at quieter than Optimized Mode with lower fan speed. X Optimized Mode: Keeps a balance between CPU temperature and fan speed.
4.5 Boot Settings The Boot Settings menu allows you to change the system boot options. Select an item and press to display the submenu. 4.5.1 Boot Device Priority The items allow you to set the sequence of boot devices where BIOS attempts to load the disk operating system. Use the arrow keys to select the desired device, then press <+>, <-> or , key to move it up/down in the priority list. 4.5.2 Boot Device Groups The Boot devices are listed in groups by device type.
M-322 4.5.3 Boot Settings Configuration Quick Boot Enabling this setting will cause the BIOS power-on self test routine to skip some of its tests during bootup for faster system boot. Options: [Disabled], [Enabled] Quiet Boot When this feature is enabled, the BIOS will display the fullscreen logo during the boot-up sequence, hiding normal POST messages.When it is disabled, the BIOS will display the normal POST messages, instead of the full-screen logo.
Wait for ‘F1’ If Error When set to Enabled, the system waits for the F1 key to be pressed when an error occurs. Options: [Disabled], [Enabled]. Hit ‘DEL’ Message Display The system displays the message “Press DEL to run Setup” during POST when set to Enabled. Options: [Disabled], [Enabled]. 4.5.4 Security Use this submenu to set the Supervisor and User passwords.
M-322 4.6 Exit Menu Select the Exit tab from the setup screen to enter the Exit BIOS Setup screen. You can display an Exit BIOS Setup option by highlighting it using the < Arrow > keys. The Exit BIOS Setup screen is shown below. Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect. Save Configuration Changes and Exit Now? [Ok] [Cancel] appears in the window.
Discard Changes and Exit Select this option to quit Setup without making any permanent changes to the system configuration. Discard Changes and Exit Setup Now? [Ok] [Cancel] appears in the window. Select Ok to discard changes and exit. Discard Changes Select Discard Changes from the Exit menu and press < Enter >. Select Ok to discard changes. Load Setup Defaults Automatically sets all Setup options to a complete set of default settings when you select this option.
M-322 Appendix A - Watchdog Timer The following is a sample program for configuring the M-322’s watchdog timer. A.
This page intentionally left blank.
M-322 Appendix B - System Resources B.
B.
M-322 B.
Hex Range Device 76h RTC Controller 77h RTC Controller 80h DMA Controller and LPC or PCI 81h-83h DMA Controller 84h-86h DMA Controller 87h DMA Controller 88h DMA Controller 89h-8Bh DMA Controller 8Ch-8Eh DMA Controller 08Fh DMA Controller 90h-91h DMA Controller 92h Reset Generator (Processor I/F) 93h-9Fh DMA Controller A0h-A1h Interrupt Controller A4h-A5h Interrupt Controller A8h-A9h Interrupt Controller ACh-ADh Interrupt Controller B0h-B1h Interrupt Controller B2h-B3h
M-322 B.
B.
M-322 IRQ Lines APIC Mode IRQ# Typical Interrupt Resource Connected to Pin 0 System timer Internal Timer / Counter 0 output / HPET #0 3 Communications Port (COM2) IRQ3 via SERIRQ, PIRQ# 4 Communications Port (COM1) IRQ4 via SERIRQ, PIRQ# 6 Floppy Disk IRQ6 via SERIRQ, PIRQ# 8 System CMOS/real time clock Internal RTC / HPET #1 9 Microsoft ACPI-Compliant System IRQ9 via SERIRQ, SCI, TCO, or PIRQ# 10 Communications Port (COM3) IRQ10 via SERIRQ, SCI, TCO, or PIRQ# 11 Communications Por
IRQ# Typical Interrupt Resource 18 Intel ICH9 Family PCI Express Root Port 3 – 2944 18 Intel ICH9 Family USB Universal Host Controller – 2936 18 Intel ICH9 Family USB2 Enhanced Host Controller – 293C 18 Realtek RTL8168C(P)/8111C(P) PCI-E Gigabit Ethernet NIC 19 Intel ICH9 2 port Serial ATA Storage Controller 2 - 2926 19 Intel ICH9 Family USB Universal Host Controller - 2939 19 Intel ICH9 Family USB Universal Host Controller - 2935 21 Intel ICH9 Family USB Universal Host Controller - 2938 2
M-322 B.
B.
M-321 Important Safety Instructions For user safety, please read and follow all instructions, WARNINGS, CAUTIONS, and NOTES marked in this manual and on the associated equipment before handling/operating the equipment. X Read these safety instructions carefully. X Keep this user’s manual for future reference. X Read the specifications section of this manual for detailed information on the operating environment of this equipment.
X Never attempt to fix the equipment. Equipment should only be serviced by qualified personnel. A Lithium-type battery may be provided for uninterrupted, backup or emergency power. WARNING: X 78 Risk of explosion if battery is replaced with one of an incorrect type. Dispose of used batteries appropriately.
M-321 Getting Service Contact us should you require any service or assistance. ADLINK Technology, Inc. Address: 9F, No.166 Jian Yi Road, Chungho City, Taipei County 235, Taiwan קᗼխࡉؑ৬ԫሁ 166 ᇆ 9 ᑔ Tel: +886-2-8226-5877 Fax: +886-2-8226-5717 Email: service@adlinktech.com Ampro ADLINK Technology, Inc. Address: 5215 Hellyer Avenue, #110, San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd.
ADLINK Technology (Europe) GmbH Address: Nord Carree 3, 40477 Duesseldorf, Germany Tel: +49-211-495-5552 Fax: +49-211-495-5557 Email: emea@adlinktech.com ADLINK Technology, Inc. (French Liaison Office) Address: 15 rue Emile Baudot, 91300 Massy CEDEX, France Tel: +33 (0) 1 60 12 35 66 Fax: +33 (0) 1 60 12 35 66 Email: france@adlinktech.com ADLINK Technology Japan Corporation Address: 151-0072 ᧲੩ㇺᷦ⼱ᐈ䊱⼱㩷 1-1-2 ᦺᣣ↢ᐈ䊱⼱䊎䊦 8F Asahiseimei Hatagaya Bldg.
