CSA-5200
4.3 Connectors and Jumpers
4.3.1 PCIe x4 Connector (PCIE1)
Pin Signal Pin Signal
A1 PRSNT1#
B1
+12V
A2 +12V
B2
+12V
A3 +12V
B3
+12V
A4 GND
B4
GND
A5 JTAG2
B5
SMCLK
A6 JTAG3
B6
SMDAT
A7 JTAG4
B7
GND
A8 JTAG5
B8
+3.3V
A9 +3.3V
B9
JTAG1
A10 +3.3V
B10
3.3Vaux
A11 PERST#
B11
WAKE#
A12 GND
B12
RSVD
A13 REFCLK+
B13
GND
A14 REFCLK-
B14
PETp0
A15 GND
B15
PETn0
A16 PERp0
B16
GND
A17 PERn0
B17
PRSNT2#
A18 GND
B18
GND
A19 RSVD
B19
PETp1
A20 GND
B20
PETn1
A21 PERp1
B21
GND
A22 PERn1
B22
GND
A23 GND
B23
PETp2
A24 GND
B24
PETn2
A25 PERp2
B25
GND
A26 PERn2
B26
GND
A27 GND
B27
PETp3
A28 GND
B28
PETn3
A29 PERp3
B29
GND
A30 PERn3
B30
RSVD
A31 GND
B31
PRSNT2#
A32 RSVD
B32
GND
