Product specifications

©2006 S.I. Tech, Inc. USB Fiber Product Equipment Manual
7
IOGear 160GB USB 2.0 HDD
Creative WebCam Live! Pro
Creative WebCam Live! Motion
ADS USB 2.0 Turbo Webcam
Sony Micro Vault 128MB Flash
Lexar Pro Jumperdrive 2GB Flash
SanDisk Cruzer Mini Flash Drive 128MB
Sony Combo flash drive and Memory Stick Reader
Passmark Loop back plug
BAFO USB 2.0 Hub (NEC Chip)
Belkin Tetra Hub (Cypress Chip)
D-Link DUB7 7port Hub (Philips Chip)
USB 1.1
Digital Persona 4000 fingerprint reader
Logitech 4000 webcam
3Com Camera
MS USB Hub/Keyboard + Optical Mouse
Dell enhanced Hub/Keyboard + Optical Mouse
Lexar Jumperdrive 128MB USB 1.1 Flash
Lomega Zip drive
Zebsx Z-3080 Barcode Scanner
Wacom Intuous Tablet
Edgeport/4 Serial Converter
Griffen PowerMate USB volume knob
DISASSEMBLY PROCEDURE
1. Disconnect power
2. There are 6 (4x40) Phillips head screws (see drawing below). Remove screws using suitable screwdriver.
3. Carefully remove cover from the device.
4. To remove PCB from base, remove 4 (6 X 32) binding head screws using a screwdriver.
NOTICE: End of Life Product Disposal
In accordance with Waste Electrical & Electronic Equipment (WEEE) directive of
European Union countries, do not throw (dispose) these products into household waste
containers. Products should be taken to authorized material recyclers in your country. For
further information, contact http://www.erp-recycling.org
.
