Total Access 1240 Installation and Maintenance Practice
5-88 61179605L5-5B
SHDSL Loop 1 Performance Screen
The SHDSL Loop 1 Performance screen (see Figure 5-71) provides information on loop errors
in current and previous 15 minute and 24 hour time intervals.
Figure 5-71. SHDSL Loop 1 Performance Screen
The SHDSL Loop 1 Performance screen fields are described in Table 5-61.
Table 5-61. SHDSL Loop 1 Performance Screen Fields
Field LTU Description NTU Description
Interface Mode This field displays the interface mode.
Values include the following:
•2-wire
•4-wire
This field displays the interface mode.
Values include the following:
•2-wire
•4-wire
ES This field displays the number of CRC
errors from the unit.
This field displays the number of CRC
errors from the SHDSL modem.
SES This field displays the number of SES
errors from the unit.
This field displays the number of SES
errors from the SHDSL modem.
UAS This field displays the number of UAS
errors from the unit.
This field displays the number of UAS
errors from the SHDSL modem.
LOSWS This field displays the number of
LOSWS errors from the unit.
This field displays the number of
LOSWS errors from the SHDSL
modem.
CVC This field displays the number of CVC
errors from the unit.
This field displays the number of CVC
errors from the SHDSL modem.
09/01/05 03:15
Total Access 1240
SHDSL Loop 1 Performance
Interface Mode : 2-wire
Cur 15 Min Prev 15 Min Cur 24 Hour Prev 24 Hour
LTU NTU LTU NTU LTU NTU LTU NTU
ES : 00000 N/A 00000 N/A 00000 N/A 00000 N/A
SES : 00000 N/A 00000 N/A 00000 N/A 00000 N/A
UAS : 00025 N/A 00893 N/A 02358 N/A 00000 N/A
LOSWS : 00025 N/A 00893 N/A 02358 N/A 00000 N/A
CVC : 00000 N/A 00000 N/A 00000 N/A 00000 N/A
'N' - Next Loop 'P' - Prev Loop 'S' - Select Loop '?' - System Help
