61179605L5-5B B-1
Appendix B
SCA File Format
SCA FORMAT
The Total Access 1240 System Configuration Archive (SCA) file can be edited according to the
following format and guidelines.
File Format
The top line is a date code used to check compatibility to current software version. Do not
modify this entry.
Bridge User Ports: Settings are in decimal format except for MAC Address which is in Hex
format.
:DATECODE 06/14/05
:BEGIN //isfs/BRIDGEPORTSSETTINGS
Internal Filename (Do not Change)
05/10/05 Date Code (Do not Change)
user1b1, Port Identifier (Do not Change)
No Circuit ID, Circuit ID - Text String
0,35,1,1,0,0,0,1, See Table B-1 for fields a, b, c, d, e, f, g, and h
No MAC Address, MAC Address 1 to filter on - xx:xx:xx:xx:xx:xx
No MAC Address, MAC Address 2 to filter on - xx:xx:xx:xx:xx:xx
No MAC Address, MAC Address 3 to filter on - xx:xx:xx:xx:xx:xx
No MAC Address, MAC Address 4 to filter on - xx:xx:xx:xx:xx:xx
No MAC Address, MAC Address 5 to filter on - xx:xx:xx:xx:xx:xx
•
•
•
:END //isfs/BRIDGEPORTSSETTINGS Internal Filename (Do not Change)
