Section 5, User Interface - Logging on to the Total Access 1240
61179605L5-5B 5-3
LOGGING ON TO THE TOTAL ACCESS 1240
To login to the Total Access 1240 system, perform the following steps:
1. Establish the physical connection to the Total Access 1240.
2. If a craft port session is being used, proceed to step 3. If using a Telnet session proceed to
step 4.
3. Press
CTRL+R until the Login prompt appears.
The Login screen is displayed in Figure 5-2. The Total Access 1240 system requires the
login name and associated password.
4. Enter the default login name, “ADMIN” (or the configured login name with System
Administrator privileges), and press
ENTER.
5. Enter the default password, “PASSWORD” (or the configured password), and press
ENTER.
Figure 5-2. Login Screen
NOTE
The Login name and Password fields are case sensitive. The default
values are all uppercase. For more information, refer to “Password
Control Menu” on page 5-36.
Total Access 1240 - IPoE Fed
Login: ADMIN
Password: ********
