Technical Specifications

Item #: Qty #:
Model #:
Project #:
B-1
FEATURES:
One piece Deep Drawn sink bowl design.
Sink bowl is 10" x 14" x 5". (
7-PS-45 sink bowl size is 16" x 20" x 8"
7-PS-49 sink bowl size is 16" x 14" x 8"
All sink bowls have a large liberal radii with a minimum dimension of 2"
and are rectangular in design for increased capacity.
Keyhole wall mount bracket.
Stainless steel basket drain 1-1/2" IPS.
Specific Features:
7-PS-50 features lever operated drain and built-in overflow with
plastic overflow tube and spring clamps. P-Trap is 1 1/2".
7-PS-54 features P-Trap only. P-Trap is 1 1/2".
7-PS-20 4" O.C. deck mounted centerset faucet furnished with aerator.
7-PS-50 & 7-PS-60 4" O.C. splash mounted gooseneck faucet, chrome
plated & furnished with aerator.
7-PS-45 Same as above plus 2 Support Brackets (Hardware Included).
7-PS-67 features lever operated drain.
7-PS-68 4" O.C. splash mounted gooseneck faucet with Wrist Handles,
chrome plated & furnished with aerator.
CONSTRUCTION:
All TIG welded.
Welded areas blended to match adjacent surfaces and to a satin finish.
Die formed Countertop Edge with a No-Drip offset.
One sheet of stainless steel - No Seams.
MATERIAL:
Heavy gauge type 304 series stainless steel.
Wall mounting bracket is Galvanized and of offset design.
All fittings are brass / chrome plated unless otherwise indicated.
MECHANICAL:
Faucet supply is 1/2" IPS male thread hot and cold.
7-PS-60
7-PS-68
7-PS-70
7-PS-71
7-PS-50
7-PS-54
7-PS-67
7-PS-45
Features
Large Size
Sink Bowl
16" x 20" x 8"
7-PS-45
Features
Large Size
Sink Bowl
16" x 14” x 8"
7-PS-20
SINGLE HOLE PUNCH
Faucet omitted
DOUBLE HOLE PUNCH
Faucet omitted
LARGE SIZE SINK BOWLS
SPLASH MOUNTED FAUCETS
For Replacement Faucets & Upgrades, Drains & Accessories
visit our website at www.advancetabco.com
DECK MOUNTED FAUCET
Keyhole Bracket for
easier installation and
greater stability.
Wrist Handles
STAINLESS STEEL
HAND SINKS
STANDARD
NEW YORK GEORGIA TEXAS NEVADA
Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]
www.advancetabco.com
Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.
Email Orders To: [e-mail]. For Smart Fabrication™ Quotes, Email To: [e-mail] or Fax To: 631-586-2933
Standard Faucet conforms to NSF 61 Standard 9. An optional faucet
upgrade is required for compliance to AB 1953 Standards.
7-PS-49
