Lite Series Sink Spec Sheets

Length Width Bowl Size Bowl Drbd. Length # of Drbrd. Aprox.
MODEL # LWA & B Depth C Drbrds. Location Wt Cubes
FE-1-1515-X 20" 20 3/4" 12" N/A 0 None 38 lbs. 11
FE-1-1620-X 21" 25 3/4" 12" N/A 0 None 42 lbs. 12
FE-1-1620-18RorL-X 36 1/2" 25 3/4" 12" 18" 1 R or L 55 lbs. 18
FE-1-1620-18RL-X 52" 25 3/4" 12" 18" 2 R & L 67 lbs. 25
FE-1-1812-X 23" 23 3/4" 12" N/A 0 None 42 lbs. 13
FE1-1812-18RorL-X 38 1/2" 23 3/4" 12" 18" 1 R or L 57 lbs. 22
FE1-1812-18RLX 54" 23 3/4" 12" 18" 2 R & L 65 lbs. 23
FE-1-1824-X 23" 29 3/4" 14" N/A 0 None 60 Ibs. 16
FE-1-1824-24RorL-X 44 1/2" 29 3/4" 14" 24" 1 R or L 105 Ibs. 28
FE-1-1824-24RL-X 66" 29 3/4" 14" 24" 2 R & L 110 lbs. 26
FE-1-2424-X 29" 29 3/4" 14" N/A 0 None 90 Ibs. 20
FE-1-2424-24RorL-X 50 1/2" 29 3/4" 14" 24" 1 R or L 103 lbs. 34
FE-1-2424-24RLX 72" 29 3/4" 14" 24" 2 R & L 122 lbs. 44
FE-2-1620-X 37" 25 3/4" 12" N/A 0 None 72 lbs. 18
FE-2-1620-18RorL-X 52 1/2" 25 3/4" 12" 18" 1 R or L 84 lbs. 25
FE-2-1620-18RL-X 68" 25 3/4" 12" 18" 2 R & L 100 lbs. 32
FE-2-1812-X 41" 23 3/4" 12" N/A 0 None 65 lbs. 18
FE-2-1812-18RorL-X 56 1/2" 23 3/4" 12" 18" 1 R or L 78 lbs. 26
FE-2-1812-18RLX 72" 23 3/4" 12" 18" 2 R & L 84 lbs. 44
FE-2-2424-X 53" 29 3/4" 14" N/A 0 None 124 lbs. 33
FE-2-2424-24RorL-X 74 1/2" 29 3/4" 14" 24" 1 R or L 132 lbs. 38
FE-2-2424-24RLX 96" 29 3/4" 14" 24" 2 R & L 140 lbs. 50
NEW YORK GEORGIA TEXAS NEVADA
Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]
www.advancetabco.com
Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.
Email Orders To: [e-mail]. For Smart Fabrication™ Quotes, Email To: [e-mail] or Fax To: 631-586-2933
Item #: Qty #:
Model #:
Project #:
E-6
FEATURES:
Backsplash has tile edge for ease of installation.
Sink bowls are 3/4" coved corner and meet NSF requirements.
Rolled Rim Edge for additional strength.
15”x15”, 16”x20” & 18”x18” Sink Bowls are 12” deep.
18”x24” & 24”x24” Sink Bowls are 14” deep.
9" Backsplash.
CONSTRUCTION:
All TIG welded.
Welded areas blended to match adjacent surfaces
and to a satin finish.
Gussets welded to a die-embossed reinforced plate.
MATERIAL:
1 5/8" diameter galvanized legs with
1" adjustable plastic bullet feet.
Entire unit is 18 gauge 304 stainless steel.
Gussets - galvanized steel.
MECHANICAL:
• Supply is 1/2" IPS hot & cold.
• Faucet holes on 8" centers.
• Faucets are not included (see accessories).
• Waste drains are 1 1/2" IPS S/S basket type, located
in center of sink bowl, and are included.
OPTIONAL:
• FE-SS-12 S/S Leg Upgrade For Sinks w/ 12” Deep Bowls
• FE-SS-14 S/S Leg Upgrade For Sinks w/ 14” Deep Bowls
K-700
Remo vable Si de
Splashes F its
Left OR Right
Side
1
8 GAUGE STAINLESS STEEL
FE SERIES - FABRICATED SINKS
One & Two Compartments
2 COMP.
1 COMP.
15"x15"
16"x20"
18"x18"
16"x20"
18"x18"
24"x24"
18"x24"
24"x24"
Rolled R im Edge
For Additional Strength
