FEATURES:
ELAG Top is furnished with 1 5/8” sanitary rolled rim on front and rear & square ends.
FLAG Top is furnished with 1 5/8” sanitary rolled rim on front and square ends, and
1 1/2” backsplash on rear.
KLAG Top is furnished with 1 5/8” sanitary rolled rim on front and square ends, and 5”
backsplash at rear.
Two hat-channels stud welded under tabletop to reinforce and maintain a level work surface.
Aluminum die cast “leg-to-shelf” clamp secures shelf to leg eliminating unsightly nuts and
bolts. Undershelf is fully adjustable.
CONSTRUCTION:
All TIG welded. Exposed weld areas polished to match adjacent surface.
Top is sound deadened.
Roll formed embossed galvanized hat channels are secured to top by means of structural
adhesive and weld studs.
Gussets welded to support hat channels.
MATERIAL:
TOP: 16 gauge stainless steel type “430” series.
SHELF: 18 gauge galvanized steel.
LEGS: 1 5/8” diameter tubular galvanized steel. Galvanized steel gussets.
1” adjustable plastic bullet feet.
STAINLESS STEEL
ECONOMY WORK TABLES
REF-O
ELAG-X Series
Flat Top
FLAG-X Series
1 1/2” Backsplash
KLAG-X Series
5” Backsplash
Plastic Bullet Feet standard on
ELAG, FLAG & KLAG Series
Made
in the
USA
Made
in the
USA
All 8 ft. Tables Provided With 6 Legs
L Model # WT.
Cu.
Ft. WT.
Cu.
Ft. Model # WT.
Cu.
Ft.
FLAT TOP 1 1/2” SPLASH 5” SPLASH
24”
ELAG-182-X
37 lbs. 3
- -
30”
ELAG-180-X
42 lbs. 4
- -
36”
ELAG-183-X
47 lbs. 5
- -
48”
ELAG-184-X
58 lbs. 7
- -
60”
ELAG-185-X
65 lbs. 8
- -
72”
ELAG-186-X
79 lbs. 10
- -
24” WIDE
24”
ELAG-242-X
42 lbs. 3
FLAG-242-X
42 lbs. 3
KLAG-242-X
46 lbs. 5
30”
ELAG-240-X
48 lbs. 4
FLAG-240-X
48 lbs. 4
KLAG-240-X
51 lbs. 6
36”
ELAG-243-X
55 lbs. 5
FLAG-243-X
55 lbs. 5
KLAG-243-X
58 lbs. 7
48”
ELAG-244-X
67 lbs. 7
FLAG-244-X
67 lbs. 6
KLAG-244-X
71 lbs. 9
60”
ELAG-245-X
78 lbs. 8
FLAG-245-X
78 lbs. 8
KLAG-245-X
84 lbs. 12
72”
ELAG-246-X
93 lbs. 10
FLAG-246-X
93 lbs. 9
KLAG-246-X
97 lbs. 14
84”
ELAG-247-X
106 lbs. 8
FLAG-247-X
106 lbs. 8
KLAG-247-X
111 lbs. 15
96”
ELAG-248-X*
110 lbs. 13
FLAG-248-X*
110 lbs. 12
KLAG-248-X*
131 lbs. 16
30” WIDE
24”
ELAG-302-X
47 lbs. 5
FLAG-302-X
47 lbs. 5
KLAG-302-X
51 lbs. 9
30”
ELAG-300-X
52 lbs. 5
FLAG-300-X
52 lbs. 5
KLAG-300-X
57 lbs. 7
36”
ELAG-303-X
62 lbs. 6
FLAG-303-X
62 lbs. 6
KLAG-303-X
65 lbs. 9
48”
ELAG-304-X
77 lbs. 8
FLAG-304-X
77 lbs. 8
KLAG-304-X
81 lbs. 9
60”
ELAG-305-X
93 lbs. 10
FLAG-305-X
93 lbs. 9
KLAG-305-X
96 lbs. 11
72”
ELAG-306-X
110 lbs. 13
FLAG-306-X
110 lbs. 11
KLAG-306-X
112 lbs. 14
84”
ELAG-307-X
125 lbs. 9
FLAG-307-X
125 lbs. 9
KLAG-307-X
127 lbs. 17
96”
ELAG-308-X*
131 lbs. 17
FLAG-308-X*
131 lbs. 15
KLAG-308-X*
134 lbs. 16
36” WIDE
36”
ELAG-363-X
73 lbs. 8
FLAG-363-X
73 lbs. 6
KLAG-363-X
75 lbs. 9
48”
ELAG-364-X
92 lbs. 8
FLAG-364-X
97 lbs. 8
KLAG-364-X
95 lbs. 11
60”
ELAG-365-X
116 lbs. 10
FLAG-365-X
116 lbs. 9
KLAG-365-X
114 lbs. 14
72”
ELAG-366-X
134 lbs. 13
FLAG-366-X
134 lbs. 11
KLAG-366-X
134 lbs. 17
96”
ELAG-368-X*
164 lbs. 17
FLAG-368-X*
157 lbs. 15
KLAG-368-X*
166 lbs. 22
