Technical Specifications

NEW YORK GEORGIA TEXAS NEVADA
Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]
www.advancetabco.com
Customer Service Available To Assist You 1-800-645-3166 8:30 am - 8:00 pm E.S.T.
Email Orders To: [e-mail]. For Smart Fabrication™ Quotes, Email To: [e-mail] or Fax To: 631-586-2933
Item #: Qty #:
Model #:
Project #:
STAINLESS STEEL
HAND SINKS
WALL MOUNTED MULTI-STATIONS
with Tubular Supports
B-13
FEATURES:
Square corner construction for extra duty applications.
Tubular stainless steel supports allow full clearance underneath.
10” High Backsplash.
1-1/8" diameter, 8” O.C. faucet holes.
Stainless steel “Z" brackets (2) supplied each unit.
CONSTRUCTION:
All TIG welded.
Welded areas blended to match adjacent surfaces and
to a satin finish.
Die formed tubular wall brackets.
MATERIAL:
All 16 gauge type “304" stainless steel.
1 5/8" tubular stainless steel wall brackets.
Stainless steel gussets.
MECHANICAL:
Supply is 1/2" hot and cold.
Faucet holes 8” on centers.
Faucets and foot pedals are not included (see accessories).
Waste drain is 1-1/2" basket type, and is included.
FEATURES:
Tubular stainless steel supports allow full clearance underneath.
8 1/2” High Backsplash.
1-1/8" diameter, 8” O.C. faucet holes.
Stainless steel “Z" brackets (2) supplied each unit.
CONSTRUCTION:
All TIG welded.
Welded areas blended to match adjacent surfaces and
to a satin finish.
Die formed tubular wall brackets.
MATERIAL:
All 14 gauge type “304" stainless steel.
1 5/8" tubular stainless steel wall brackets.
Stainless steel gussets.
MECHANICAL:
Supply is 1/2" hot and cold.
Faucet holes 8” on centers.
Faucets and foot pedals are not included (see accessories).
Waste drain is 1-1/2" basket type, and is included.
Multi-Wash Multi-Functional
Standard “19” Series
NSF Series
Optional Faucets &
Knee Valve Assembly
Available (See Below)
NOTE: 96” Units provided with 2 Drains
For Replacement Faucets & Upgrades, Drains & Accessories
visit our website at www.advancetabco.com
Standard Faucet conforms to NSF 61 Standard 9
and compliance to AB 1953 Standards.
19-18-23
19-18-48
19-18-60
19-18-72
19-18-96
50 lbs.
60 lbs.
70 lbs.
80 lbs.
100 lbs.
10
15
18
21
28
# of Approx Approx
Length MODEL Faucets Required Wt Cubes
1
2
2
3
4
23”
48”
60”
72”
96”
FS-WM-48
FS-WM-60
FS-WM-72
FS-WM-96
60 lbs.
70 lbs.
80 lbs.
100 lbs.
10”
14”
14”
16”
11”
15”
10”
32”
43”
55”
67”
91”
15
18
21
28
(L) # of Approx Approx
Length MODEL Faucets Required ABCWt Cubes
2
2
3
4
48”
60”
72”
96”
1
7 1/2” Wide
8" Deep Bowl
19 1/2” Wide
8" Deep Bowl
MODEL Optional Accessories QTY
K-121 Gooseneck Spout ____
7-PS-32 Knee Valve Assembly ____
K-175 Electronic Faucet ____
K-88 Relocate Drain to Rear for A.D.A ____
K-13 S/S Soap Dispenser ____
K-13WMS Factory Install K-13 to Backsplash ____
K-121
7-PS-32
19-18-60 Shown
