Assembly Instructions for Utility Carts

CONTENTS
(2) Tubular Handles
(3) Shelves (Stainless Steel or Wire)
(4) Casters
(4) Rubber Bumpers
(4) Plastic Tapered Split sleeves (Per Shelf)
TOOLS REQUIRED
Rubber Mallet
Step 1:
Position top shelf onto
tubular handles.
(Figure 1)
Step 2:
Position Plastic Split
Sleeve at desired
location (4) required
and lower shelf onto
split sleeve. (Figure 2)
Step 3:
Repeat Step 2 for
middle and lower shelf.
(Figure 3)
Step 4:
Place rubber bumper
onto bottom
of tubular handles.
(Figure 4)
Step 5:
Install caster into the
bottom end of each
tubular handle (Use
rubber mallet if required).
NOTE: Ensure each (4) split sleeves
are located at the same height.
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
PLEASE NOTE: The following instructions are showing a
Stainless Steel solid shelf being assembled. These instructions
apply for assembling a Wire Utility Cart as well.
