18 Contents installation Frustration Preparing to install Connection installation Safety instructions For the installer For the user Appliance description 6453 K8 ‘The electronic control panel 6453 K8 The ceramic Properties The touch control Standby mode Switching on the hob Selecting the cooking stage Locking and unlocking Switch off the cooking zone Activating the bring-to-the-boil boost Switching off the hob Residual heat indicator Operating time mit Fryer combination The correct cookware General Practic
Installation These build-in hobs are intended 1o be inserted in a worktop severs {Fig. 3). Only an approved electrical instanter should connect the appliance, since it is then guaranteed that the statutory regulations and connection specifications of the local electricity supply company are complied with. Make a 750 x 480 mm cutout in the worktop with a distance front and behind respectively (Fig. 1).
Connection installation 20 LP switches, fuses, and con factors are deemed 10 be suitable violators. “The main connection lead to be used must be at least of type HOOVES-F or HOVHANESS-F. Cross-section; 1582 1. Lay the hob on the worktop with the ceramic facing downwards. 2. Remove the cover of the ELT connection on the lower side of the appliance housing.
Only when the hob is installed is it ensured that no live parts or leads can be touched. Turn on the fuses or main switch only when the appliance is installed. The appliance must be installed in the furniture according to these installation and operating instructions. it should be expressly noted that we cannot accept any liability for direct or indirect damage caused by wrong connection or improper installation. When being repaired, the appliance must always be disconnected from the mains supply.
For the installer For the user 22 Safety instructions On the basis of the safety specifications, manufactures are obliged 1o give the following instructions: For fitting in furniture, the attached installation instructions should be followed. ~ While you are cooking, the hob surfaces get hot. You should therefore basically keep small children well away. Overheated fats and oils rapidly ignite. If you are cooking food in fat or oit {e. g. chipped potatoes), you are advised to remain in the vicinity.
Appliance description 6453 K8 1 Cooking zone 14,5 cm aid, 1200 W (Halogen) 2 Cooking zone 18,0 cm aid, 1800 W (Halogen) 3 Cooking zone 21,0 cm aid, 2300 W 4 frying zone 26,5 x 17,0 cm, 1500/2400 W 5 Cooking zone operating buttons 6 Fryer combination bunion 7 Locking button 8 Convoy button 23
6453 K8 Properties 24 The electronic control panel Control buttons and power Locking contraindication for rear theft cooking zones Locking indicator Contort bunions and power indicator fot rear tight cooking zone Fryer bouillon: U Pryor indicator Contort bunions and pa war indication for front right cooking zone Colonist bunions {3/} and power OO bunion indicator for rant deft cooking zoo OO indicator ] The ceramic This new hob generation provides you with a completely flat cooking area that can be installe
The touch control When switched off, the hob is in standby mode. Al indicators are dark, When the Ongoing button is pressed, the hob control system is switched on with a time delay — the Power ON luminous indicator fighting up. Within around 5 seconds, one of the hotplates must be switched on. Otherwise, for reasons of safety the hob switches off again. When the button i§ first pressed, the respective hotplate switches on at stage “1°.
Switching off the hob Residual heat indicator Operating time limit Fryer combination The control system can be switched off at any arbitrary time by pressing the On/OHf button. When an individual hotplate or the whole cooking area is switched off, any available residual heat is highlighted as a luminous "H” An operating time limit separately applies to each hotplate and cooking stage, i. 8. the hotplate switches off automatically after three hours, should you aver have forgotten to switch it off.
The correct cookware ‘The better the cookware, the better the cooking result You can tell good cookware by the pan base and not by the material from which the pan is made. The base should be as thick and even as possible. it should also nat be rough cast-iron cookware), since it may then cause scratches when being moved about. Use high-sided pans for dishes with a lot of liquid. The contents will then not boil over, Take care not to boil enamel pans dry.
Table of boiling/ frying for the hob 28 Practical hints Power indicator 9 Suitable for Bringing large amounts of water 10 the boil, cooking pasta Deep-trying chipped potatoes, frying meat, . g. goulash, thorough cooking, . g.
Cleaning and caring for your ceramic cooking area 1. Thoroughly clean the cooking area before first use and then at regulars intervals. 2. Never use any aggressive cleaners, such as e. g. coarse scouring agents or abrasive pan cleaners. 3. Thoroughly clean the whole hob once per week. To do this, use “Idol” stainless steel polish, “Stahl-Fix™ or “WK-Top®, Then clean the whole hob thoroughly with clean water, and rub it dry with a clean cloth.
Stains Sand grains Loss of decor 30 {lime stains, iridescent stains, metallic boom-tike discolorations {due 1o pan abrasion] formed during cooking) are best removed when the hob is stile warm {(not hot). To do this, you should also use “Si dot* stainless steel polish, “Stark-Fix”, or “WK-Top". You may well need 10 repeat the cleaning process. You should then proceed exactly as described under 3. which have fallen on fo the hob may cause scratches if pans are said aver them.
What can be the matter the indicator lamps do not come on? 1. you may not have operated all appropriate bunions or 2. the fuse in the domestic wiring system {fuse box) has tripped. the fuses repeatedly trip? Please call an approved electrical installer, Should you still wish 1o call our service cents for any of the specified falls or because the appliance is being wrongly operated, the service engineer’s visit cannot be made free of charge even during the guarantee period.
1f your build-in hob has a fault, please quote the following data, when calling our service center: FNE 2 AEG Austerity AG AEG Domestic Appliances Ltd Posthaste 1036 Customer Care Department D-80327 Kornberg 1 55-77 High Street .
