Overload behaviour up to 105 % continuous;
in battery mode > 105 % for 10 s
Short circuit behaviour 3 x I
N
for 300 ms
Battery
Autonomy time (full load with internal battery)
Protect C. 6000 8 min.
Protect C. 10000 5 min.
Autonomy times with external optional battery expansions
(only for Protect C. models):
Coupled
battery modules
Autonomy times (full load)
C.6000
C.10000
1
26 min.
16 min.
2
47 min.
27 min.
3
67 min.
42 min.
4
94 min.
53 min.
Rated direct voltage (intermediate circuit)
Protect C. 6000 (S) 240 Vdc
Protect C. 10000 (S) 240 Vdc
Battery charging current
Protect C. 6000 2.0 A
Protect C. 6000 S 4.2 A
Protect C.
10000 2.0 A
Protect C.
10000 S 4.2 A
Recharge time ~ 7 h (UPS with internal
to 90% of rated capacity battery only)
(Protect C – models) ~ 11
h (with 1 battery
expansion)
~ 16 h (with 2 battery
expansions)
~ 24 h (with 3 battery
expansions)
