15
EN
Max. site altitude up to 1000m at rated power;
if the UPS is used above than
1000m, decreasing as follows:
Colour Blackline
Weight:
Protect C. 6000 90 kg
Protect C. 6000 S 35 kg
Protect C. 6000 BP 65 kg
Protect C.
10000 93 kg
Protect C.
10000 S 38 kg
Protect C.
10000 BP 68 kg
Dimension W x H x D:
Protect C. 6000 (S
/ BP) 260 mm x 717 mm x 570 mm
Protect C. 10000 (S
/ BP) 260 mm x 717 mm x 570 mm
Guidelines
The Protect C complies with the product norm EN 50091.
The CE symbol on the unit certifies the compliance to the EG
guidelines for 73/23 EEC low voltage and for 89/336 EEC
electromagnetic compatibility (EMC), when following the
installation instructions in the manual.
For the 73/23 EEC low voltage guidelines
Reference number EN 62040-1-1 : 2003
For 89/336-EMV guidelines
Reference number EN 50091-2 : 1995
EN 61000-3-2 : 1995
EN 61000-3-3 : 1995
Warning:
This is a UPS product
for restricted sales for
users only with appropriate knowledge. To avoid
interference,
restrictions according installation
or additional measures may be required.
i
Altitude (
m) 1000 1500 2000 2500 3000
Power
100% 95% 90% 85% 80%
