Operating instructions
Table Of Contents
- 1 Notes on these Operating Instructions
- 2 General Information
- 3 Safety
- 4 Set-Up and Operation
- 5 Commissioning
- 6 Electrical Start-Up
- 7 Interfaces and communication
- 8 Signalling and Error Correction
- 9 Parallel operation
- 10 Maintenance
- 11 Storage, Dismantling and Disposal
- 12 Glossary
8
2 General Information
2.1 Technology
Protect C is an Uninterruptible Power
Supply
(UPS) for essential loads such as PCs,
workstations, servers, network components,
telecommunication equipment
and similar
devices. It consists of:
♦ Mains filter with overvoltage Protection (appliance
Protection
/ class D) and mains energy backfeed Protection
♦ Rectifier section with PFC logic (power factor correction unit)
♦ Separate battery charger with switch mode power supply
technology
♦ Integrated sealed, maintenance-free battery system
(Protect C.6000 / C.10000) as energy storage medium
with downstream DC/DC converter unit
♦ IGBT inverter for continuous supply of connected loads
with sinusoidal AC voltage
♦ Automatic electronic bypass (SBS = Static Bypass
Switch) as additional passive redundancy
♦ Manual bypass for maintenance and service purposes
(with SBS activation when activated)
♦ Digital signal processor controlled control unit
i
