Protect PV.600/800 OD Series - Operating Instructions
Page 20 of 100 8000041160 BAL
DANGER
Auxiliary voltage despite emergency shutdown
Risk to life due to electric shock.
Disconnect the equipment safely.
Skilled personnel with a Working with Live Current certifi-
cate.
DANGER
Residual voltage from capacitors
Risk to life due to electric shock.
Disconnect the equipment safely.
Discharge capacitors.
i
Before commissioning the equipment, connect the PE con-
ductor in accordance with DIN VDE 0100-540 (IEC 60364-1).
i
Using residual current protective devices (RCD) alone is not
permitted.
i
Keep the equipment clean to minimise leakage currents.
DANGER
Contact with leakage current
Risk to life due to electric shock.
Disconnect the equipment safely.
2.6.3 Dangers of Photovoltaic Equipment
i
The safety of inverters in photovoltaic equipment must be
compliant with DIN EN 62109-1.
i
Install a load interrupter switch on the AC side of the equip-
ment to provide voltage backfeed protection (Q26) in accord-
ance with DIN EN 62109-1 (IEC 62040).
