Operating instructions

Protect PV.600/800 OD Series - Operating Instructions
8000041160 BAL Page 25 of 100
4 Equipment Specifications
4.1 Type Designation
4.1.1 Inverter Cabinet
Protect PV.690-OD-Vx-GER-x
x = options
GER = country/region/standard
Vx = version (optional)
OD = outdoor housing
690 kVA = nominal AC output
PV = photovoltaic series
Protect = AEG family
Table 4 - Inverter cabinet designation (example)
4.1.2 Inverter Stack
G685 D345/1155 N3refg-P690püx
p = with microprocessor control
ü = additional monitoring device
x = special version
P = transistors
690 kVA = nominal AC output
Characteristic properties
r = forced characteristic from built-in regulator
e = converter unit with adjustable characteristic curve
f = converter unit with smoothing and
filtering equipment on the input side
g = converter unit with smoothing and
filtering equipment on the output side
N = mains load type = grid
3 = nominal output frequency 50-60 Hz
1155 A = nominal AC output current at X26
345 V = nominal output voltage at X26
D = three-phase current - output current type
685 V = nominal input voltage
G = direct current - input current type
Table 5 - Inverter stack designation according to DIN 41752 (example)
4.2 Structure
The Protect PV.6x0/8x0-OD is a component that is part of a com-
plete solar power plant. The following is located in the outdoor sta-
tion:
