Protect PV.600/800 OD Series - Operating Instructions
8000041160 BAL Page 45 of 100
5.7.3 Table of Faults
Temperature monitoring
Fault/Message
Deactivat-
ing
Self-
acknowl-
edging
Signal-
ling
DOU message
IGBT 1 stack temperature warning
x
!Equipment temperature fault!
IGBT 2 stack temperature warning
x
!Equipment temperature fault!
IGBT 1 stack temperature fault
x
#Equipment temperature fault#
IGBT 2 stack temperature fault
x
#Equipment temperature fault#
IGBT supply air undertemperature
x
!Ambient temperature fault!
IGBT supply air temperature
warning
x
!Ambient temperature fault!
IGBT supply air temperature fault
x
#Ambient temperature fault#
Unit exhaust air
temperature warning
x
!Equipment temperature fault!
Unit recirculation air 2
temperature warning
x
!Equipment temperature fault!
Unit exhaust air
temperature fault
x
#Equipment temperature fault#
Unit recirculation air 2
temperature fault
x
#Equipment temperature fault#
Recirculation air 1
undertemperature
x
!Ambient temperature fault!
Recirculation air 1 temperature
warning
x
!Ambient temperature fault!
Recirculation air 1 temperature
fault
x
#Ambient temperature fault#
Temperature sensor fault
IGBT 1 stack
x
#Temperature sensor fault#
Temperature sensor fault
IGBT 2 stack
x
#Temperature sensor fault#
Temperature sensor fault
IGBT supply air temperature
x
#Temperature sensor fault#
Temperature sensor fault
equipment exhaust air
temperature
x
#Temperature sensor fault#
Temperature sensor fault
recirculation air 2 temperature
x
#Temperature sensor fault#
Temperature sensor fault
recirculation air 1 temperature
x
#Temperature sensor fault#
