Protect PV.600/800 OD Series - Operating Instructions
8000041160 BAL Page 47 of 100
Unit monitoring systems
Fault/Message
Deactivat-
ing
Self-
acknowl-
edging
Signalling
DOU message
Monitoring
fan fault cabinet fan
x
!Fan failure!
Monitoring
fan fault stack fans
x
Monitoring K7
feedback signal INV output
contactor
x
#Fault K7 feedback signal#
Monitoring
parameter limits
x
!Parameter limit fault!
Monitoring
PCB ID
x
#Self-test fault#
Monitoring
EEPROM
x
#EEPROM fault#
Monitoring
serial EEPROM
x
!System error!
Monitoring
watchdog
x
#Watchdog#
Monitoring
15 V supply voltage
x
#15 V supply voltage fault#
Monitoring
IGBT stack
x
#Stack fault#
Monitoring
short circuit/overload
x
#Short circuit#
Monitoring
load current transformer
#Load current transformer fault#
Monitoring
stack current transformer
x
#Stack current transformer fault#
Monitoring
inverter output voltage
x
#AC voltage deviation#
Monitoring
stack overcurrent
x
#Stack overcurrent#
Monitoring
mains synchronisation
x
#Synchronisation fault#
Monitoring
communication parallel CAN
x
!Communication fault
parallel CAN!
Monitoring
communication remote
monitoring
x
!Remote monitoring fault!
