Protect PV.600/800 OD Series - Operating Instructions
Page 48 of 100 8000041160 BAL
DC voltage monitoring system
Fault/Message
Deactivat-
ing
Self-
acknowl-
edging
Signalling
DOU message
Monitoring
DC monitoring system
x
#DC voltage deviation#
Grid monitoring system
Fault/Message
Deactivat-
ing
Self-
acknowl-
edging
Signalling
DOU message
Field rotation or phase fault
x
#Field rotation fault#
Monitoring
grid overfrequency
x
#Mains frequency deviation#
Monitoring
grid underfrequency
x
#Mains frequency deviation#
Monitoring
grid overvoltage
x
#Mains frequency deviation#
Monitoring
grid undervoltage
x
#Mains frequency deviation#
Monitoring
symmetry fault
x
#Mains symmetry fault#
i
In the event of faults that have an impact on the grid opera-
tor mains (grid), the equipment owner must inform the grid
operator. In this instance, the equipment may only be
switched back on after the cause of the fault has been
properly clarified and discussion with the grid operator has
taken place.
