Protect PV.600/800 OD Series - Operating Instructions
Page 54 of 100 8000041160 BAL
i
Be aware of the equipment's centre of gravity.
Implementation
1. Move forks under the pallet, secure the equipment.
2. Carefully lift the equipment and transport it to its intended in-
stallation location.
3. Carefully lower the equipment at the installation location and
set it down without any jolts. Move the forklift or lowlift truck
backwards.
4. Move the forks under the equipment, secure the equipment,
then unscrew and remove its screw connections from the pal-
let. If necessary, remove the ventilation grilles first.
5. Lift the equipment and position it at the installation location.
6. Carefully lower the equipment, feed in the cables from below
( terminal diagram (*.TD)) and set the equipment down with-
out any jolts.
7. Check the stability of the equipment and secure it.
8. Move the forklift or lowlift truck backwards.
