Protect PV.600/800 OD Series - Operating Instructions
8000041160 BAL Page 57 of 100
Thread
Electrical
connection
[Nm]
Mechanical connection
Cheese head
screw strength
category 5.8
Hexagon screw
strength category
8.8
Slotted cheese head
screws
DIN 84
[Nm] [Nm] [Nm]
M4
1.2 1.3 2.0 1.2
M5
2.0 2.65 4.0 2.0
M6
3.0 4.4 7.0 2.5
M8
6.0 10.5 17.0 3.5
M10
10.0 - 33.0 4.0
M12
15.5 - 56.0 -
M16
30.0 - 140.0 -
M20
52.0 - 260.0 -
M24
80.0 - 445.0 -
Table 11 - Tightening torques
These values apply to electrical and mechanical screw connec-
tions. They do not apply to floor attachment with dynamic stress
applied.
7.4 DC/AC Mains
DANGER
Working with voltages up to 1 kV
Risk to life due to electric shock.
Comply with BGV A3, DIN VDE 0105 (EN 50110).
Skilled personnel with a Working with Live Current certifi-
cate.
i
Install load interrupter switches as supply/reverse voltage
protection (fire service switch in the DC input (IEC 62040)).
Secure the cables in the PG cable glands to provide strain relief.
The PG cable glands are located in the cabinet base.
i
Observe the bending radius of the supply lines.
With one bend:
bending radius = 10 x diameter of supply line.
