You can scroll through the measured values using the "v" and "^"
keys.
You can use the "COM interface" menu item to look up the status-
es of the communication PCBs.
You can use the "AUX signals" menu item to look up the status of
optional general signals on the remote signalling.
9.3.2 Blocking
The "Blocking" menu can be called from the "Main menu". After
you have entered the current password to LOGIN, you can block
operation of the inverter (switching ON/OFF and fault acknowl-
edgement). The password must be entered digit by digit and then
acknowledged using the ENTER key.
The default password set by the factory is: 1201.
In menus where switching operations are normally possible, block-
ing is indicated by a key.
9.3.3 Fault History
The "Fault history" menu can be reached from the "Main menu". A
data logger that records the inverter's fault history is integrated in
the inverter unit. The last 20 fault messages, starting from the cur-
rent date or a selected date, can be displayed.
9.3.4 Settings
The "Settings" menu can also be reached from the "Main menu".
Here you can set the following parameters in the submenus:
LCD contrast
•
Language •
Real time and •
Acoustic signal generator for indicating faults and operation •
of the keyboard
9.3.5 Information
The "Information" menu can be reached from the "Main menu". In-
formation about the unit type, firmware versions and the communi-
cation options available can be looked up here.
9.3.6 Service
The "Service" menu can be reached from the "Main menu". The
following submenus can be called here:
Password
•
Disconnection protection parameters •
After you have entered the current password, you can change the
password for blocking the operation in the "Password" menu. The
password must be entered digit by digit and then acknowledged
using the ENTER key. The range from 0000 to 9999 is available
for entering the password.
