10.2.5 Care
Lubrication
Carry out the following care measures for the equipment:
• Lubricate hinges, rods and guide rails after cleaning.
• After cleaning rubber door seals, rub lightly with a rubber care
product such as deer tallow.
• Clean weather protection grid seals and rub with a rubber care
product. When dismantling the weather protection grid, carry
out care measures for the entire seal.
10.2.6 Replacement
Replacing the battery
The 3 V battery on PCB A17 should be replaced after about
10 years, as it is exposed to thermal loads.
Replacing the radial ventilator/radial fan
A radial fan must be replaced if it is defective or runs out of round;
however, this must be carried out after 10 years of operation at the
latest.
When fans are replaced, the starting capacitors must be replaced
too.
WARNING
Rotating parts
Injury to fingers and hands possible.
Do not reach into rotating parts.
De-energise fans.
Cabinet Component Plug
INV Radial fan M1 -X91.1
INV Radial fan M2 -X91.2
DC Radial fan M3 -X91.3
DC Radial fan M4 -X91.4
AC Radial fan M5 -A91.5
Table 27 - Plugs for fan monitoring
Removing and installing radial fans M1 to M5:
The fans M1 to M5 are located on the top of the cabinet.
It is necessary to remove the roof (Figure 10).
1. Unscrew the screw connections from the cable clip.
2. Remove fan connectors X91.1 to X91.5.
3. Unscrew and remove all 4 screw connections from the mount-
ing plate.
