IAE84850FB USER MANUAL EN User Manual Hob
www.aeg.com CONTENTS 1. SAFETY INFORMATION............................................................................................. 2 2. SAFETY INSTRUCTIONS.............................................................................................4 3. PRODUCT DESCRIPTION...........................................................................................7 4. QUICK GUIDE............................................................................................................. 8 5.
ENGLISH 3 manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.
www.aeg.com • • • • • • • • • NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket. CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. WARNING: Danger of fire: Do not store items on the cooking surfaces. Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.
ENGLISH • Seal the cut surfaces with a sealant to prevent moisture to cause swelling. • Protect the bottom of the appliance from steam and moisture. • Do not install the appliance adjacent to a door or under a window. This prevents hot cookware falling from the appliance when the door or the window is opened. • Each appliance has cooling fans on the bottom.
www.aeg.com • Do not put cutlery or saucepan lids on the cooking zones. They can become hot. • Do not operate the appliance with wet hands or when it has contact with water. • Do not use the appliance as a work surface or as a storage surface. • If the surface of the appliance is cracked, disconnect immediately the appliance from the power supply. This to prevent an electrical shock.
ENGLISH 7 3. PRODUCT DESCRIPTION 3.1 Cooking surface layout 3 1 1 Induction cooking zone 2 Control panel 3 Flexible induction cooking area consisting of four sections 1 2 3.2 Cooking zone panel 2 1 3 4 11 5 6 7 10 To see the available settings touch the appropriate symbol. Symbol Comment 1 ON / OFF To activate and deactivate the hob. 2 Menu To open and close the menu. 3 Zone selection To open the slider for the selected zone.
www.aeg.com 10 Symbol Comment 0-9 - To show the current heat setting. FlexiBridge To switch between three modes of the function. 11 3.3 OptiHeat Control (3 step Residual heat indicator) WARNING! III / II / I There is a risk of burns from residual heat. The indicator shows the level of the residual heat. The induction cooking zones produce the heat necessary for the cooking process directly in the bottom of the cookware. The glass ceramic is heated by the heat of the cookware. 4.
ENGLISH Settings 9 Child Lock Stopwatch Setup Assisted Cooking Language Key Tones Buzzer Volume Display Brightness Service Demo Mode License Show Software Version Alarm History Reset All Settings To leave the Menu touch or the right side of the display, outside of the pop-up window. To navigate through the Menu description appears. Follow the tips to easily navigate through the Menu. use or . scroll the list up and use or touch leave the Menu.
www.aeg.com acoustic signal sounds and the hob deactivates. Remove the object or clean the control panel. • the hob gets too hot (e.g. when a saucepan boils dry). Let the cooking zone cool down before you use the hob again. • you use incorrect cookware or there is no cookware on a given zone. The white cooking zone symbol blinks and the induction cooking zone deactivates automatically after 1 minute. • you do not deactivate a cooking zone or change the heat setting.
ENGLISH zones connected to a single phase exceeds 3680 W. • The function decreases the power of the other cooking zones connected to the same phase, which has an influence on the available heat setting. • The maximum heat setting is visible on the slider. Only the digits in white are active. • If a higher heat setting is not available reduce it for the other cooking zones first. 11 To deactivate the function set the heat setting to 0.
www.aeg.com The function does not stop when you lift the pot. To reset the function and start it again manually touch , select Reset from the pop-up window. The function starts counting from 0. To Pause the function for one cooking session touch and select Pause from the pop-up window. Select Start to continue counting. 6.8 Pause When the function operates only and symbols can be used. All other symbols on the control panel are locked. The function does not stop the timer functions.
ENGLISH 1. Touch on the display to open the Menu. 2. Select Settings >Setup > Display Brightness from the list. 3. Choose the appropriate level. To leave the Menu touch or the right side of the display, outside of the pop-up window. To navigate through the Menu use or . 6.14 Assisted Cooking This function adjusts the temperature to different types of food and maintains it throughout cooking. It can only be activated for the left front cooking zone. on the display to open the 1. Touch Menu. 2.
www.aeg.com 7.2 FlexiBridge Standard mode heat setting for each zone separately. This mode is active when you activate the hob. It connects the sections into two separate cooking zones. You can set the heat setting for each zone separately. Correct cookware position: To use this mode you have to place the cookware on the three connected sections. If you use cookware smaller Correct cookware position: blinks on the than two sections the display and after 1 minute the zone switches off.
ENGLISH 15 settings. The hob detects the position of the cookware and adjusts the pre-set power level accordingly. You can place the pot in the front, middle or rear position. If you place the cookware at the front you get the highest heat setting (i.e. 9). To decrease it, move the cookware to the middle (heat setting - 5) or rear position (heat setting -1). Correct cookware position: To use this mode you have to place the cookware on the four connected sections.
www.aeg.com 8. HINTS AND TIPS WARNING! Refer to Safety chapters. 8.1 Cookware For induction cooking zones a strong electro-magnetic field creates the heat in the cookware very quickly. Use the induction cooking zones with suitable cookware. Cookware material • correct: cast iron, steel, enamelled steel, stainless steel, multi-layer bottom (with a correct marking from a manufacturer). • not correct: aluminium, copper, brass, glass, ceramic, porcelain.
ENGLISH 17 Heat setting Use to: Time (min) Hints 1 Keep cooked food warm. as necessary Put a lid on the cookware. 1-2 Hollandaise sauce, melt: butter, chocolate, gelatine. 5 - 25 Mix from time to time. 1-2 Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on. 2-3 Simmer rice and milkbased dishes, heat up ready-cooked meals. 25 - 50 Add at least twice as much liquid as rice, mix milk dishes halfway through the procedure. 3-4 Steam vegetables, fish, meat.
www.aeg.com • Remove when the hob is sufficiently cool: limescale rings, water rings, fat stains, shiny metallic discoloration. Clean the hob with a moist cloth and a non-abrasive detergent. After cleaning, wipe the hob dry with a soft cloth. • Remove shiny metallic discoloration: use a solution of water with vinegar and clean the glass surface with a cloth. • The surface of the hob has horizontal grooves. Clean the hob with a moist cloth and some detergent with smooth movement from left to right.
ENGLISH 19 Problem Possible cause Remedy You cannot activate the highest heat setting. Another zone is already set to the highest heat setting. First reduce the power of the other zone. The sensor fields become hot. The cookware is too large or Put large cookware on the you put it too near to the rear zones if possible. controls. There is no sound when you touch the panel sensor fields. The sounds are deactivated. The display does not react to the touch.
www.aeg.com Problem and a number come on. Possible cause Remedy The diameter of the bottom of the cookware is too small for the zone. Use cookware with correct dimensions. Refer to "Technical data". FlexiBridge operates. One or more sections of the function mode which operates are not covered by the cookware. Place the cookware on the correct number of sections of the function mode which operates or change the function mode. Refer to "Flexible induction cooking area". PowerSlide operates.
ENGLISH • To replace the damaged mains cable, use the cable: H05BB-F or H03V2V2-F which withstands a temperature of 70°C or higher. min. 12 mm 11.4 Assembly min. 500mm min. 50mm min. 60mm R 5mm min. 55mm +1 490+1mm 750 mm If the appliance is installed above a drawer, the hob ventilation can warm up the items stored in the drawer during the cooking process. min.
www.aeg.com 12. TECHNICAL DATA 12.1 Rating plate Model IAE84850FB Typ 62 D4A 05 CA Induction 7.35 kW Ser.Nr. ................. AEG PNC 949 597 465 00 220 - 240 V / 400 V 2N 50 - 60 Hz Made in Germany 7.35 kW 12.2 Software Licences The software included in the hob contains copyrighted software that is licensed under the BSD, fontconfig, FTL, GPL-2.0, LGPL-2.0, LGPL-2.1, libJpeg, zLib/ libpng, MIT, OpenSSL / SSLEAY ISC, Apache 2.0 and others.
ENGLISH Diameter of circular cooking zones (Ø) Middle rear Right front 21.0 cm 18.0 cm Lenght (L) and width (W) of the cooking area Left L 45.6 cm W 21.6 cm Energy consumption per cooking zone (EC electric cooking) Middle rear Right front 189.1 Wh / kg 178.3 Wh / kg Energy consumption of the Left cooking area (EC electric cooking) 187.0 Wh / kg Energy consumption of the hob (EC electric hob) 185.
867349009-B-212018 www.aeg.
