L6FB50472 USER MANUAL DE Benutzerinformation Waschmaschine
www.aeg.com INHALTSVERZEICHNIS 1. SICHERHEITSHINWEISE............................................................................................. 3 2. SICHERHEITSANWEISUNGEN...................................................................................5 3. MONTAGE................................................................................................................... 6 4. GERÄTEBESCHREIBUNG......................................................................................... 11 5.
DEUTSCH 1. 3 SICHERHEITSHINWEISE Lesen Sie vor der Montage und dem Gebrauch des Geräts zuerst die Gebrauchsanleitung. Bei Verletzungen oder Schäden infolge nicht ordnungsgemäßer Montage oder Verwendung des Geräts übernimmt der Hersteller keine Haftung. Bewahren Sie die Anleitung immer an einem sicheren und zugänglichen Ort zum späteren Nachschlagen auf. 1.
www.aeg.com 1.2 Allgemeine Sicherheit • • • • • • • • • • • Nehmen Sie keine technischen Änderungen am Gerät vor. Überschreiten Sie nicht die maximale Beladungsmenge von 7 kg (siehe Kapitel „Programmübersicht“). Der Betriebswasserdruck am Wassereinlass der Wasserversorgung muss zwischen 0,5 bar (0,05 MPa) und 8 bar (0,8 MPa) liegen. Die Lüftungsöffnung im Gerätesockel darf nicht von einem Teppich, einer Matte oder einem Bodenbelag blockiert werden.
DEUTSCH 5 (siehe Abschnitt „Zubehör - Bausatz Wasch-TrockenSäule“). 2. SICHERHEITSANWEISUNGEN 2.1 Montage 2.2 Elektrischer Anschluss • Entfernen Sie die Verpackungsmaterialien und die Transportschrauben. • Bewahren Sie die Transportschrauben an einem sicheren Ort auf. Wenn das Gerät in Zukunft umgesetzt werden soll, müssen sie wieder angebracht werden, um die Trommel zu verriegeln und dadurch interne Schäden zu vermeiden. • Seien Sie beim Umsetzen des Gerätes vorsichtig, da es sehr schwer ist.
www.aeg.com • Verwenden Sie keinen Verlängerungsschlauch, falls der Zulaufschlauch zu kurz ist. Wenden Sie sich an den Kundendienst, um einen anderen Zulaufschlauch zu erhalten. • Sie können den Ablaufschlauch auf maximal 400 cm verlängern. Fragen Sie beim Kundendienst nach einem anderen Ablaufschlauch und der Schlauchverlängerung. 2.4 Gebrauch WARNUNG! Verletzungs-, Stromschlag-, Brand-, Verbrennungsgefahr sowie Risiko von Schäden am Gerät.
DEUTSCH 3. Entfernen Sie die Karton-Abdeckung und Styroporverpackungsteile. 7. Entfernen Sie den Styroporschutz von der Geräteunterseite. 1 2 4. Öffnen Sie die Tür und entfernen Sie das Styroporteil aus der Türdichtung und alle Teile aus der Trommel. 5. Legen Sie das Gerät vorsichtig mit der Rückseite darauf ab. 6. Legen Sie das vordere Styroporteil unter dem Gerät auf den Boden. Achten Sie darauf, die Schläuche nicht zu beschädigen. 8. Ziehen Sie das Gerät nach oben, sodass es wieder aufrecht steht.
www.aeg.com Stellen Sie sicher, dass die Luftzirkulation unter dem Gerät nicht durch Teppiche beeinträchtigt wird. Vergewissern Sie sich, dass das Gerät weder die Wand noch andere Geräte berührt. 2. Schrauben Sie die Füße zum Ausrichten des Geräts weiter heraus oder hinein. 10. Lösen Sie die drei Schrauben mit dem mitgelieferten Schraubenschlüssel. WARNUNG! Schieben Sie weder Karton noch Holz oder ähnliche Materialien unter die Stellfüße, um das Gerät auszurichten. 11.
DEUTSCH 3.3 Wasserzulaufschlauch 9 Verwenden Sie keinen Verlängerungsschlauch, falls der Zulaufschlauch zu kurz ist. Wenden Sie sich an den Kundendienst, um einen anderen Zulaufschlauch zu erhalten. 1. Schließen Sie den Wasserzulaufschlauch an der Rückseite der Maschine an. 2. Drehen Sie ihn nach links oder rechts, je nach Position des Wasserhahns. 3.4 Aquastop-Vorrichtung Der Zulaufschlauch verfügt über eine Aquastop-Vorrichtung.
www.aeg.com 2. Am Rande eines Beckens Befestigen Sie die Führung am Wasserhahn oder an der Wand. Stellen Sie sicher, dass die Kunststoffführung beim Abpumpen nicht herausrutschen kann. Achten Sie darauf, dass sich das Ende des Ablaufschlauchs nicht im Wasser befindet. Anderenfalls könnte Schmutzwasser in das Gerät zurückfließen. 3. In ein Standrohr mit Belüftungsöffnung - Stecken Sie den Ablaufschlauch direkt in das Ablaufrohr. Orientieren Sie sich an der Abbildung.
DEUTSCH 11 4. GERÄTEBESCHREIBUNG 4.1 Sonderfunktionen Ihre neue Waschmaschine erfüllt alle modernen Anforderungen an eine effektive und schonende Wäschepflege, bei einem geringen Wasser-, Energieund Waschmittelverbrauch. • Die ProSense-Technologie passt automatisch die Programmdauer an die Wäsche in der Trommel an, um optimale Waschergebnisse in der kürzest möglichen Zeit zu erzielen.
www.aeg.com 5. BEDIENFELD 5.1 Bedienfeldbeschreibung 2 1 3 Programme Zeitvorwahl Baumwolle Baumwolle Eco Pflegeleicht Feinwäsche Wolle/Seide 20 Min. - 3 kg Baumwolle 20° Daunen Sportwäsche 95° 1400 Zeit Sparen 60° 1200 40° 800 30° Ohne Schleudern Spülstopp Vorwäsche U./Min. Option 7 6 Temp.
DEUTSCH A 13 Die Digitalanzeige zeigt Folgendes an: • Programmdauer (z. B. • Zeitvorwahl (z. B. ). oder ). • Programmende ( ). • Fehlercode ( ). B Anzeige Extra Spülen Leuchtet, wenn diese Option ausgewählt ist. C Die Anzeige schemenge. D Kindersicherungsanzeige. E Türverriegelungsanzeige. blinkt während der Messung der Wä- 6. PROGRAMMWAHLSCHALTER UND TASTEN 6.1 Ein/Aus 6.3 Temp. Halten Sie diese Taste einige Sekunden lang gedrückt, um das Gerät ein- oder auszuschalten.
www.aeg.com Schleudergang aus und pumpt das Wasser ab. Das Gerät pumpt das Wasser nach etwa 18 Stunden automatisch ab. Schalten Sie die Option Ohne Schleudern ein • Wählen Sie diese Option zum Ausschalten aller Schleudergänge. Nur das Abpumpprogramm ist möglich. • Die entsprechende Anzeige leuchtet auf. • Stellen Sie diese Option für Feinwäsche ein. • Der Spülgang verbraucht bei einigen Waschprogrammen mehr Wasser. Die Schleuderdrehzahl kann reduziert werden. 6.
DEUTSCH 15 7. PROGRAMME 7.1 Programmübersicht Waschprogramme Programm Programmbeschreibung Waschprogramme Baumwolle Weiße und bunte Baumwollwäsche. Normal und leicht verschmutzt. Weiße und bunte Baumwollwäsche Baumwolle Eco Weiße und bunte Baumwollwäsche. Normal und leicht verschmutzt. Standardprogramme für die auf dem Energielabel angegebenen Verbrauchswerte.
www.aeg.com Programm Programmbeschreibung Pumpen/Schleudern Schleudern der Wäsche und Abpumpen des in der Trommel verbliebenen Wassers. Alle Gewebearten, außer Wollwäsche und Feinwäsche. 1) Während dieses Programms dreht sich die Trommel langsam, um einen schonenden Waschgang zu gewährleisten. Die Trommel scheint sich nicht oder nicht ordnungsgemäß zu drehen, aber dies ist normal für dieses Programm. 2) Dieses Programm ist für den täglichen Gebrauch geeignet.
DEUTSCH Programm Standardtemperatur Temperaturbereich Maximale Schleuder- Maximale Beladrehzahl dung Schleuderdrehzahlbereich 1400 U/min 1400 U/min – 800 U/min Pumpen/Schleudern1) 17 7 kg 1) Stellen Sie die Schleuderdrehzahl ein. Stellen Sie sicher, dass sie für die Art der zu waschenden Wäsche geeignet ist. Wenn Sie die Option Kein Schleudern auswählen, ist nur das Abpumpprogramm verfügbar. Feinwäsche Wolle/Seide 20 Min.
www.aeg.com 7.2 Woolmark Apparel Care Blau Das Waschprogramm Wolle dieser Maschine wurde von der Firma Woolmark auf das Waschen von Wolltextilien mit der Pflegekennzeichnung „Handwäsche“ getestet und zugelassen, vorausgesetzt, dass die Wäsche gemäß der Anleitung auf dem Kleidungsetikett und gemäß den Angaben des Maschinenherstellers gewaschen wird. Beachten Sie die Trocken- und Waschanleitung auf dem Kleidungsetikett.
DEUTSCH starten Sie das Programm ohne Wäsche. 19 So werden alle eventuellen Verunreinigungen aus Trommel und Bottich entfernt. 10. TÄGLICHER GEBRAUCH WARNUNG! Siehe Kapitel Sicherheitshinweise. 10.1 Einschalten des Geräts 1. Stecken Sie den Netzstecker in die Netzsteckdose. 2. Öffnen Sie den Wasserhahn. 3. Halten Sie die Taste einige Sekunden lang gedrückt, um das Gerät einzuschalten. Es ertönt eine kurze Melodie (falls eingeschaltet). Der Programmwahlschalter wird automatisch auf Baumwolle gesetzt.
www.aeg.com Entfernen Sie nach dem Waschgang bei Bedarf Waschmittelreste aus der Waschmittelschublade. 10.4 Überprüfen Sie die Position der Klappe 1. Ziehen Sie die Waschmittelschublade bis zum Anschlag heraus. 2. Drücken Sie den Hebel nach unten und ziehen Sie die Schublade heraus. 1 2 3. Drehen Sie die Klappe nach oben, wenn Sie Waschpulver verwenden. Klappe in der UNTEREN Position: • Verwenden Sie keine Gelwaschmittel oder Flüssigwaschmittel mit dicker Konsistenz.
DEUTSCH gewünschte Waschprogramm. Die entsprechende Programmanzeige leuchtet auf. Die Kontrolllampe der Taste Start/Pause blinkt. Das Display zeigt die voraussichtliche Programmdauer an. 2. Berühren Sie die entsprechenden Tasten, um die Temperatur und/oder Schleuderdrehzahl zu ändern. 3. Schalten Sie bei Bedarf eine oder mehrere Optionen durch Berühren der entsprechenden Tasten ein. Die zugehörigen Anzeigen leuchten im Display und die angezeigten Informationen ändern sich entsprechend.
www.aeg.com 10.9 Unterbrechen eines Programms und Ändern der Optionen 3. Schließen Sie die Tür und berühren Sie die Taste Start/Pause. Das Programm bzw. die Zeitvorwahl läuft weiter. Wenn das Programm bereits gestartet wurde, können Sie nur einige der Optionen ändern: 10.12 Programmende 1. Berühren Sie die Taste Start/Pause. Die zugehörige Kontrolllampe blinkt. 2. Ändern Sie die Optionen. Die im Display angezeigten Informationen ändern sich entsprechend. 3.
DEUTSCH • Die Trommel dreht sich regelmäßig weiter, um Knitterfalten in der Wäsche zu vermeiden. • Die Tür bleibt verriegelt. • Sie müssen das Wasser abpumpen, um die Tür öffnen zu können: 1. Berühren Sie bei Bedarf die Taste U./ Min., um die vom Gerät vorgeschlagene Schleuderdrehzahl zu verringern. 2. Drücken Sie Start/Pause, um den Waschgang fortzusetzen. 3. Wenn das Programm beendet ist und die Türverriegelungsanzeige erlischt, können Sie die Tür öffnen. 4.
www.aeg.com a. unterbrechen Sie das Programm und öffnen Sie die Tür (siehe „Öffnen der Tür nach erfolgtem Programmstart oder während der Zeitvorwahl“). b. verteilen Sie die Wäsche mit der Hand neu, so dass die Wäschestücke gleichmäßig verteilt sind. c. Drücken Sie die Taste Start/ Pause. Die Schleuderphase wird fortgesetzt. 11.2 Hartnäckige Flecken Für manche Flecken sind Wasser und Waschmittel nicht ausreichend.
DEUTSCH VORSICHT! Verwenden Sie keinen Alkohol, keine Lösungsmittel und keine Chemikalien. VORSICHT! Reinigen Sie die Metallflächen nicht mit einem Reinigungsmittel auf Chlor-Basis. 12.2 Entkalkung Wenn die Wasserhärte Ihres Leitungswassers hoch oder mittel ist, empfehlen wir die Verwendung eines Entkalkers für Waschmaschinen. Prüfen Sie die Trommel regelmäßig auf Kalkablagerungen.
www.aeg.com 1 2 2. Entfernen Sie das Oberteil des Pflegemittelfachs, um die Reinigung zu vereinfachen, und spülen Sie es mit fließendem warmen Wasser aus, um das angesammelte Waschmittel zu beseitigen. Setzen Sie nach der Reinigung das Oberteil wieder ein. 12.7 Reinigen der Ablaufpumpe WARNUNG! Ziehen Sie den Netzstecker aus der Netzsteckdose. Kontrollieren Sie regelmäßig das Ablaufpumpensieb und sorgen Sie dafür, dass es sauber ist. 3.
DEUTSCH 27 2 1 2 1 2. Stellen Sie einen geeigneten Behälter unter die Öffnung der Ablaufpumpe, um das abfließende Wasser aufzufangen. 3. Drücken Sie die beiden Hebel, und ziehen Sie den Ablaufkanal nach vorne, um ihn zu öffnen. 1 7. Schließen Sie den Ablaufkanal und drehen Sie das Sieb gegen den Uhrzeigersinn, um es zu entfernen. 2 1 1 2 4. Lassen Sie das Wasser ablaufen. 5. Wenn der Behälter voll ist, schließen Sie den Ablaufkanal und leeren Sie den Behälter. 6.
www.aeg.com 1. Schrauben Sie den Zulaufschlauch vom Wasserhahn ab und reinigen Sie das Sieb. 1 2 11. Setzen Sie das Sieb wieder in die dafür vorgesehenen Führungen ein und drehen Sie es im Uhrzeigersinn. Achten Sie darauf, dass Sie das Sieb richtig fest anziehen, um Wasserlecks zu vermeiden. 3 2. Lockern Sie die Ringmutter, um den Zulaufschlauch vom Gerät zu entfernen. 2 1 3. Reinigen Sie das Ventilsieb an der Geräterückseite mit einer Zahnbürste. 12. Schließen Sie die Pumpenabdeckung.
DEUTSCH 29 kann, entfernen Sie das im Zulaufschlauch und in der Ablaufpumpe verbliebene Wasser. 45° 20° 12.9 Notentleerung Kann das Gerät das Wasser nicht abpumpen, führen Sie den unter „Reinigen des Ablauffilters“ beschriebenen Vorgang aus. Reinigen Sie bei Bedarf die Pumpe. 1. Ziehen Sie den Netzstecker aus der Netzsteckdose. 2. Schließen Sie den Wasserhahn. 3. Stecken Sie die beiden Enden des Zulaufschlauchs in einen Behälter und lassen Sie das Wasser aus dem Schlauch fließen. 4.
www.aeg.com • - Die Stromzufuhr ist nicht konstant. Warten Sie, bis die Netzspannung wieder konstant ist. • - Keine Kommunikation zwischen den elektronischen Bauteilen des Geräts. Schalten Sie das Gerät aus und wieder ein. • – Das Aqua-Control-System ist eingeschaltet. Schalten Sie das Gerät aus und drehen Sie den Wasserhahn zu. Wenden Sie sich an einen autorisierten Kundendienst. WARNUNG! Schalten Sie das Gerät vor der Überprüfung aus. 13.2 Mögliche Störungen Störung Das Programm startet nicht.
DEUTSCH 31 Störung Mögliche Abhilfe Das Gerät pumpt das Wasser nicht ab. • Stellen Sie sicher, dass der Siphon nicht verstopft ist. • Vergewissern Sie sich, dass der Ablaufschlauch nicht geknickt oder zu stark gekrümmt ist. • Vergewissern Sie sich, dass das Ablaufsieb nicht verstopft ist. Reinigen Sie ggf. das Sieb. Siehe „Reinigung und Pflege“. • Vergewissern Sie sich, dass der Wasserablaufschlauch ordnungsgemäß angebracht ist.
www.aeg.com Störung Mögliche Abhilfe Die Programmdauer erhöht oder verringert sich während der Ausführung des Programms. • Die ProSense-Funktion passt die Programmdauer an die Wäscheart und -menge an. Siehe „ProSense Beladungserkennung“ im Kapitel „Täglicher Gebrauch“. Die Waschergebnisse sind nicht zufriedenstellend. Zu viel Schaum in der Trommel während des Waschprogramms. Nach dem Waschgang befinden sich Waschmittelrückstände in der Waschmittelschublade.
DEUTSCH Programme Beladung (kg) EnergieWasserUngefähverbrauch verbrauch re Pro(kWh) (Liter) grammdauer (in Minuten) Restfeuchte (%)1) Baumwolle 60 °C 7 1,34 68 157 52 Baumwolle 40 °C 7 0,78 61 157 52 Pflegeleicht 40 °C 3 0,60 56 103 35 Feinwäsche 40 °C 3 0,55 59 81 35 Wolle/Seide 30 °C 1,5 0,45 62 75 30 7 0,92 45 250 52 3,5 0,68 35 204 52 3,5 0,59 36 189 52 Standardprogramme Baumwolle Standardprogramm Baumwolle 60 °C Standardprogramm Baumwolle 60 °C Standard
www.aeg.com Kaltwasser Wasseranschluss 1) Maximale Beladung Baumwolle Energieeffizienzklasse Schleuderdrehzahl 7 kg A+++ Höchstwert 1400 U/min 1) Schließen Sie den Zulaufschlauch an einen Wasserhahn mit einem 3/4'' -Außengewinde an. 16. ZUBEHÖR 16.1 Verfügbar bei www.aeg.com/shop oder einem autorisierten Händler 16.3 Bausatz Wasch-TrockenSäule Nur mit geeignetem, von AEG zugelassenem Zubehör können die Sicherheitsstandards des Geräts gewährleistet werden.
DEUTSCH 35 17. UMWELTTIPPS Recyceln Sie Materialien mit dem Symbol . Entsorgen Sie die Verpackung in den entsprechenden Recyclingbehältern. Recyceln Sie zum Umwelt- und Gesundheitsschutz elektrische und elektronische Geräte. Entsorgen Sie * Geräte mit diesem Symbol nicht mit dem Hausmüll. Bringen Sie das Gerät zu Ihrer örtlichen Sammelstelle oder wenden Sie sich an Ihr Gemeindeamt.
