in.chant table of contents TM Table of contents features ........................................................................................... 3 warning .......................................................................................... 4 overview in.chant dimensions ......................................................6 installation in.chant ............................................................................ 7 keypad ................................................................
in.
in.chant features TM in.chant™ Digital media player for spas The in.chant has been designed specifically for use in the spa environment. The unit can handle multiple digital audio sources such as iPods, USB memory sticks, universal MP3 players and it’s ready for SIRIUS satellite receivers. The in.chant also includes an AM/FM radio receiver. Main features Any of those media sources can be controlled from the edge of your spa while you’re in the water. Provided with our sleek in.k455 keypad, the in.
warning in.chant WARNING Before installing or connecting the unit, please read the following. DO NOT DISASSEMBLE OR ALTER. Doing so may result in an accident, fire or electrical shock. USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES. Failure to do so may result in fire or electrical shock. DO NOT BLOCK RADIATOR PANEL. Doing so may cause heat to build up inside and may result in fire. DO NOT PLACE HANDS OR FINGERS ON RADIATOR PANEL. Doing so may result in personal injury.
in.chant TM warning WARNING When this equipment is provided as an audio/video component for spas, UL 1563 - 5th edition requires that the following instructions (or equivalent) be provided as part of the instruction manual for the spa equipment. PREVENT ELECTROCUTION Do not connect any auxiliary components (for example cable, additional speakers, headphones, additional audio/video components, etc) to the system.
overview in.chant in.
in.chant installation TM Mounting on a horizontal or vertical surface The in.chant should be installed on a horizontal or vertical even surface. TM Whether it's horizontally or verticcally, this unit should be installed at a location above the flood level of the spa. Do not install in.chant in the upright position as illustrated above.
in.chant installation 6 7/32" 158 mm Installation in.k455 with adhesive TM The keypad should be installed directly on the edge of the spa so that it is easily accessible to the user. Drill 2x 3/8” 2x 9 mm 2 5/16" 59 mm • Using the drilling template supplied with the unit, determine the mounting location and then stick the template on the location. • Drill two 3/8” (9 mm) diameter holes at 6 7/32” (158 mm) from center to center, in the exact position according to the drilling template.
in.chant installation TM Drilling template (in.
connections in.chant TM Speakers and supply Wiring diagram ite wh ck bla black ck bla black blue power antenna USB TM wire remote in.
in.chant connections TM Important note: This unit must be supplied by a +12Vdc Limited Power source certified to UL 1585-3, Class 2 Wet or certified to UL/IEC/EN 60950-1. Red Wire Connect this wire to a constant +12V power source. exists, tape off the end of this wire to prevent shorting out of the unit. White wire Connect this wire to the left front speaker (+) positive terminal or wire. Green wire Connect this wire to the left rear speaker (+) positive terminal or wire.
connections in.chant Connecting keypad to in.chant TM The in.k455 comes with a 20 ft cable terminated with a 8-pin mini din male connector. TM To connect the keypad, simply insert the 8-pin mini din male connector into the 8-pin mini din receptable labelled "wire remote" as illustrated. 12 in.chantTM TM Wired remote in.
in.chant connections TM Connecting USB/JACK panel mount to in.chant TM To connect the auxiliary input to the in.chant simply insert both RCA connectors into their appropriate mates. (Red male RCA connector onto red female receptable and white male RCA connector into white receptable) TM To connect the USB input, simply insert USB jack into USB white receptable as illustrated. Auxiliary audio input black cables with RCA connectors USB memory stick in.
connections in.chant Connecting in.p3-110 to in.chant TM TM TM TM in.p3-110 (optional) The in.p3-110 dock station comes with a 10 ft cable terminated with a 9-pin mini din connector. TM To connect the dock station simply insert the 9-pin mini din male connector into the 9-pin mini din receptable as illustrated. in.
in.chant connections TM Connecting SIRIUS external tuner to in.chant TM Antenna The SIRIUS tuner comes with an interface cable and magnetic antenna. Sirius external Tuner (SCC1) (optional) To connect the SIRIUS external tuner, simply insert the 8-pin mini din male connector into the 8-pin mini din receptable labelled “SIRIUS” as illustrated. in.chantTM Refer to the satellite tuner operation section for activation procedure (page: 20).
basic operation in.chant Power / Shift TM Volume Up Sound adjustement Volume Down Option adjustement Source selection Menu Track Down Turning Power On / Off Press the Power / Shift key to turn the system on or off. Selecting Audio source Successive presses on the SRC key will navigate between the following audio sources: TUNER – USB – AUX – IPOD – SIRIUS Note: “SIRIUS” will be displayed only if a satellite receiver is installed.
in.chant TM or SUB (Subwoofer volume adjustment) successive presses on the Track Up or the Track Down keys will change the settings. If you select EQ (Preset Equalizer adjustment) successive presses on the Track Up or the Track Down keys alternates between OFF - JAZZ – POP – ROCK – CLASSIC – VOCAL Note that the Bass and the Treble adjustments are available only when EQ is set to OFF. To leave the Sound adjustment menu, simply press once on any of these keys (Power / Shift, SRC or Menu).
radio in.chant Radio frequencies broadcast in sterio Power / Shift Source selection / Tuner Menu MEM (Save function) Track Down Scan previous Selecting reception band Successive presses on the MENU key will navigate between the following: AM – FM - FAV FAV are your preset stations. If no preset stations have been saved, the keypad will display NO FAV. If you select FAV, successive presses on the Track Up or the Track Down keys will navigate between the stations saved in your Favorites.
in.chant TM Saving Favorite channels into preset Select the desired station, press and hold the Power / Shift key and press once on the MEM key to save. You can save up to 10 preset stations. Once the memory is full, it will automatically save the desired station over the first one. Receiving a stereo broadcast station If a stereo broadcast station is received, the stereo icon will light.
in.chant satellite Satellite channel indicator Power / Shift Source selection / SIRIUS Display Menu MEM (Save function) Track Down Scan previous Track Up Scan next Important to know It is necessary to purchase a SIRIUS Tuner, part number SCC1, to receive SIRIUS broadcasting. You also have to subscribe to SIRIUS Satellite Radio. This service is available only in North America.
in.chant TM Seeking next or previous station Pressing the Track Up or the Track Down keys makes the Tuner Seek Up or Seek Down to the next station. Press and hold the Track Up or the Track Down keys to browse much faster. Scanning next or previous station Press and hold the Power / Shift key and press once on the Track Up or the Track Down keys to start a SCAN. Stations are automatically searched for in a sequential order, starting from the station being currently received.
in.chant USB TM MP3 / WMA files reading Repeat mode Random mode Power / Shift Source selection / SIRIUS Display Menu Track Down Scan previous Important to know The device may not play inauthentic MP3 or WMA files. You can either copy all files in the ROOT directory or create Folder (PLAYLIST). Warning Turn OFF the unit to insert your USB drive. Failure to do so may damage your USB drive or cause the system to malfunction.
in.chant USB TM Seeking next or previous songs Pressing the Track Up or the Track Down keys makes the Tuner Seek Up or Seek Down to the next song. Scanning next song or previous song Press and hold the Power / Shift key and press once on the Track Up or the Track down keys to start a SCAN. Songs are automatically searched for in a sequential order, starting from the song being currently played. Each song will stay on for 10 seconds. Press once the Track Up or the Track Down keys to stop the SCAN.
iPod in.chant TM Repeat mode Random mode Power / Shift Volume Down Option adjustement Source selection / iPod Display Menu Track Down Important to know In order to connect your iPod, an optional Gecko Alliance water-tight dock station in.p3-110 is required. Some iPod models might not support the communication protocol and the files will not play. (See list of supported iPod on page 14).
in.chant iPod TM Seeking next or previous songs Pressing the Track Up or the Track Down keys will make the Tuner Seek Up or Seek Down to the next song. Scanning next song Press and hold the Power / Shift key and press once on the Track Up key to start a SCAN. Songs are automatically searched for in a sequential order, starting from the song being currently played. Each song will stay on for 10 seconds. Press once the Track Up or the Track Down keys to stop the SCAN.
accessories in.chant TM Optional in.p3-110 Optional panel mount USB port TM Optional SIRIUS connect universal tuner (SCC1) Sold separately For more information about accessories, visit our website at www.geckoalliance.com 26 Designs are subject to change without prior notice.
in.chant specifications TM Model: in.chant .100 Audio source - AM/FM tuner: AM specification • Frequency Range 530-1710 KHz Environmental: • Usable Sensitivity 32 dBuV • Operating temperature: 0˚C (32˚F) to 50˚C (122˚F) • Signal to noise Radio 50 dB • Storage temperature: -25°C (-13°F) to 85°C (185°F) • Humidity: up to 85% RH, non condensing FM specification • Water Ingress: IPx5 • Frequency Range 87.5 - 107.9 MHz • Sensitivity 8 db TM Mechanical: • Weight: 2 LBS (0.
specifications in.chant Audio source Auxiliary in: TM Other input/output Stereo RCA connectors Subwoofer: • Voltage variable output: 0 - 2 Volts max.(adj in setup) USB connection: • Impedance • Type: USB 2.0 Power antenna: • Mass storage: Up to 32 Gb • Voltage output: 12 V DC • File format: WMA and MP3 • Current: 0.2 Amps • Song name display: • Arborescence: Yes Supported - 1 level Keypad connection: • Compatible model: IPod connection: • Model supported: in.
