Specification
48
800-757-6996
FLEXIBLE METAL CONDUIT - ALUMINUM
UL Reduced Wall Aluminum Type RW
FAC (5600 Series)
Description
• Lightweight Reduced Wall Aluminum Flexible Conduit
• Premium aluminum alloy
• Interlocking design
• Proprietary lubricant and process providing a non-oil surface and product
with extra exibility
• Trade sizes 1-1/2 through 4 are made with no solder joints
Applications
Suitable for use in:
• Flexible Aluminum Conduit (FAC): A raceway of circular cross-section made
of helically wound, interlocked aluminum strip
• Accordance with NEC® Article 348 Flexible Metal Conduit Type FMC
• Exposed and concealed locations
• Utilization equipment per NEC® 348.20(A)(2)(a)
• Part of a listed assembly per NEC® 348.20(A)(2)(b)
• Equipment ground in accordance with NEC® 250.118(5)
• Other Spaces Used for Environmental Air (Plenums) per NEC® 300.22(C)
• Use in Cable Trays per NEC® 392.10(A) and Table 392.10(A)
• Raceway for Tap Conductors for Luminaires per NEC® 348.20(A)(2)(c)
and 410.117(C)
• Connection to a motor terminal enclosure per NEC® 430.223
• Class I Division 2 per NEC® 501.10(B)(2)(2)
• Neon Secondary-Circuit Wiring 1000V or Less per NEC® 600.31(A)
• Neon Secondary-Circuit Wiring Over 1000V per NEC® 600.32(A)(1)
• Manufactured Wiring Systems per 604.100(A)(2)
• Elevators, Dumbwaiters, Escalators, Moving walks, Platform and Stairway
Chairlifts per NEC® 620.21
• Under Raised Floors per NEC® 645.5(E)(1)(b)(10)
• Solar Photovoltaic (PV) Systems per NEC® 690.31(A)
• Fuel Cell Systems per NEC® 692.31
• Wind Electric Systems per NEC® 694.30(A)
• Critical Operations Power Systems (COPS) where exibility is required per
NEC® 708.10(C)(1)(3)(b)
• Optical Fiber Cables for installation within buildings per NEC® 770.110(A)(1)
• Communications Circuit Wires and Cables for installation within buildings
per NEC® 800.110(A)(1)
• Community Antenna Television and Radio Coaxial Cables for installation
within buildings per NEC® 820.110(A)(1)
• Low and Medium Power Network-Powered Broadband Cables for
installation within buildings per NEC® 830.110(A)(1)
Ratings
• NFPA 70 National Electric Code (NEC®) Articles 348, 250, 300, 392, 410,
423, 430, 501, 600, 604, 620, 645, 690, 692, 694, 708, 770,
800, 820 and 830
• UL 1 Standard for Flexible Metal Conduit UL File Number E11831
Federal Specication WW-C-566C
superseded by UL 1
• UL 1479 Fire Tests of Through-Penetration Firestops UL File Number R14141
UL Classied Through-Penetrating Product
for Use in Through-Penetration
Firestop Systems
• NEMA RV 3 Application and Installation Guidelines for Flexible and Liquidtight
Flexible Metal Conduits
• C22.2 No. 56 CSA Standard for Flexible Metal Conduit and Liquid-Tight Flexible
Metal Conduit
The 3/8 Trade Size is the only Type RW FMC that is CSA Certied
• RR 93227 City of Los Angeles Electrical Testing Laboratory Research Report
Number 93227
Permits the use of 1/2 and 3/4 Trade Sizes of Type RW Flexible
Aluminum Conduit in long lengths per the Report
www.afcweb.com
