Specification Sheet

Rowan LED Sconce
RWNS Series
Features
Modern wall sconce. Can be used in hallways, entrances, restrooms
and anywhere general lighting is needed. Provides lighting in residential,
commercial, and hospitality applications. Fixture can be mounted
horizontally or vertically to a standard junction box (not included).
Construction
Back pan is die formed from 22-gauge steel. All stainless steel metal
housing construction with sealed white diffuser. Power supply connections
must be made in a junction box (not included).
Finish
Metal housing is available in satin nickel or white powder coated finish.
Diffuser
Diffuser is made of 0.10” thick standard white acrylic.
Electrical
Input 120-277VAC / 60 Hz.
Compatible with 0-10V dimmers.
LED
Integrated LED modules capable of producing:
18” - 16W, 1400 source lumens
30” - 28W, 2400 source lumens
3000K (CCT). Rated for 50,000 hrs., 90 CRI
Certification
cETLus certified for damp locations.
ADA
Warranty
Limited warranty: This fixture is free from
defects in materials and workmanship for
a period of 5 years from date-of-purchase.
Specifications and dimensions
subject to change without notice.
2345 N. Ernie Krueger Circle • Waukegan, IL. 60087 • P: 847.249.5970 • F: 847.249.2618 • AFXinc.com R0/19
DATE
LOCATION
PREPARED
BY
COMMENTS
CATALOG
NUMBER
QUANTITY
FIXTURE TYPE
Ordering Information:
18”
30”
Satin Nickel White LED Lumens CCT H W D MC
RWNS180414L30D2SN RWNS180414L30D2WH 16W 1400 3000K 18” 4” 2-1/2” 9”
RWNS300424L30D2SN RWNS300424L30D2WH 28W 2400 3000K 30” 4” 2-1/2” 15”
Source
MC
MC - Mounting Center
MC
