Specification Sheet

Rowan LED Outdoor Sconce
RWNW Series
Features
This LED light is ideal for security and general lighting. Provides lighting
in residential, commercial, and hospitality applications. Fixture can be
mounted horizontally or vertically to a standard junction box (not included).
Construction
Back pan is die formed from 22-gauge steel. All stainless steel metal housing
construction with sealed diffuser. Power supply connections must be made in
a junction box (not included).
Finish
Metal housing is available in satin nickel or white powder coated finish.
Diffuser
Diffuser is made of 0.10” thick standard white acrylic.
Electrical
Input 120-277 VAC 60 Hz.
Compatible with 0-10V dimmers.
LED
Integrated LED modules capable of producing:
20” - 22W, 2000 source lumens
36” - 42W, 4000 source lumens
Adjustable Choice 3000K, 3500K, 4000K (CCT).
Rated for 50,000 Hrs. 90 CRI.
Certification
cETLus certified for wet locations.
*ADA
Warranty
Limited warranty: This fixture is free from
defects in materials and workmanship for
a period of 5 years from date-of-purchase.
Specifications and dimensions
subject to change without notice.
2345 N. Ernie Krueger Circle • Waukegan, IL. 60087 • P: 847.249.5970 • F: 847.249.2618 • AFXinc.com R0/19
DATE
LOCATION
PREPARED
BY
COMMENTS
CATALOG
NUMBER
QUANTITY
FIXTURE TYPE
Ordering Information:
GYLS RWNS
RYDV
L
GYLS RWNS
RYDV
L
Textured Grey LED Lumens Adjustable CCT H W D MC
RWNW052020LAJD2TG 22W 2000 3000K/3500K/4000K 20” 5” 3-3/8” 10”
RWNW073640LAJD2TG 42W 4000 3000K/3500K/4000K 36” 7” 4-3/8” 18”
Textured Bronze LED Lumens Adjustable CCT H W D MC
RWNW052020LAJD2BZ 22W 2000 3000K/3500K/4000K 20” 5” 3-3/8” 10”
RWNW073640LAJD2BZ 42W 4000 3000K/3500K/4000K 36” 7” 4-3/8” 18”
Source
Source
*
*
MC
MC - Mounting Center
3000K/3500K/4000K
