138 Agilent E5505A User’s Guide
6
Absolute Measurement Examples
Table 15 Test set signal input limits and characteristics
Limits
Frequency
•
50 kHz to 1.6 GHz (Std)
•
50 kHz to 26.5 GHz (Option 001)
•
50 kHz to 26.5 GHz (Option 201)
Maximum Signal Input Power Sum of the reference and signal input power
shall not exceed +23 dBm (+30 dBm with
Option 001)
At Attenuator Output, Operating Level Range:
•
RF Phase Detectors 0 to +23 dBm (Signal Input)
+15 to +23 dBm (Reference Input)
•
Microwave Phase Detectors 0 to +5 dBm (Signal Input)
+7 to +10 dBm (Reference Input)
•
Internal AM Detector 0 to +20 dBm
Downconverters:
•
Agilent N5502A/70422A +5 to +15 dBm
•
Agilent N5507A/70427A 0 to +30 dBm
Characteristics
Input Impedance 50 Ω nominal
AM Noise DC coupled to 50 Ω load
CAUTION
To prevent damage to the test set’s hardware components, do not apply the input
signal to the test set’s signal input connector until the input attenuator (Option
001) has been set by the phase noise software, which occurs at the connection
diagram.
NOTE
Refer to the following system connect diagram examples in Chapter 18, “System
Interconnections” for more information about system interconnections.
•
Figure 307, “E5505A system connections with standard test set,” on page 403
•
Figure 308, “E5505A system connections with test set option 001,” on page 404
•
Figure 309, “E5505A system connections with test set option 201,” on page 405
