Absolute Measurement Examples

Agilent E5505A User’s Guide 145

Free-Running RF Oscillator

This measurement example will help you measure the phase noise of a

free-running RF oscillator with frequency drift >20 ppm over a period of thirty

minutes.

Required equipment

This measurement requires an 8644B reference source in addition to the

E5505A system and your DUT. (For more information, see the section

“Selecting a reference source" on page 132.) You also need the coaxial cables

and adapters necessary to connect the DUT and reference source to the test

set.

Defining the measurement

From the File menu of the E5500 User Interface, choose Open.

If necessary, choose the drive or directory where the file you want is stored.

In the File Name box, choose “FreeRF.pnm”. See Figure 96.

CAUTION

To prevent damage to the test set’s components, do not apply the input signal to

the signal input connector until the input attenuator has been correctly set for the

desired configuration, as shown in Tab l e 18 on page 152. Apply the input signal

when the connection diagram appears.

NOTE

To ensure accurate measurements allow the DUT and measurement equipment to warm

up at least 30 minutes before making the noise measurement
