Introduction and Measurement
Designing to Meet Your Needs
The E5505A Phase Noise Measurement System is a high performance
measurement tool that enables you to fully evaluate the noise characteristics
of your electronic instruments and components with unprecedented speed and
ease. The phase noise measurement system provides you with the flexibility
needed to meet today’s broad range of noise measurement requirements.
In order to use the phase noise system effectively, it is important that you have
a good understanding of the noise measurement you are making. This manual
is designed to help you gain that understanding and quickly progress from a
beginning user of the phase noise system to a proficient user of the system’s
basic measurement capabilities.
Beginning
The section “E5505A Operation: A Guided Tour" on page 35 contains a
step-by-step procedure for completing a phase noise measurement. This
measurement demonstration introduces system operating fundamentals for
whatever type of device you plan to measure.
Once you are familiar with the information in this chapter, you should be
prepared to start Chapter 4, “Expanding Your Measurement Experience. After
you have completed that chapter, refer to Chapter 14, “Evaluating Your
Measurement Results for help in analyzing and verifying your test results.
NOTE
If you have just received your system or need help with connecting the hardware or
loading software, refer to your Agilent E5505A Phase Noise Measurement System
Installation Guide now. Once you have completed the installation procedures, return to
“E5505A Operation: A Guided Tour" on page 35 to begin learning how to make noise
measurements with the system.
