PC Components Installation
19
Agilent E5505A User’s Guide 409
Step 6: Hardware Installation
To install the PC digitizer software
Step Action
1 Make sure your PC and display are on.
2 Place the manufacturer’s installation DVD-R in
the DVD-R drive of the PC.
•
The installation wizard dialog box should
automatically appear after a few
seconds. If it doesn’t, start it this way:
•
From the Start menu, select My
Computer and the DVD-R drive.
•
Find and select the file setup.exe. Click
OK.
3 Follow the instructions in the installation wizard.
•
Accept the defaults.
4 Shutdown and power off the PC and its
peripherals. Proceed to the phase noise
hardware installation procedures.
•
Leave the DVD-R in the drive. Once you
have installed the necessary hardware
and powered on the PC again, the
installation wizard will lead you through
completing the PC digitizer software
installation process.
NOTE
If you’re re-installing any of the phase noise hardware and software components in the
list, be sure to uninstall all components, then reinstall them in the order shown above.
NOTE
If you encounter any problems with the installation, contact your Agilent Technologies
Service Center. Contact information is in Appendix A, “Service, Support, and Safety
Information.”
WARNING
Disconnect all power before removing the cover to your PC. Failure to disconnect
power could result in serious injury.
CAUTION
Refer to your computer’s documentation for installation safety instructions and
specific instructions for opening your computer. Be sure to perform these
procedures in a properly grounded environment. Agilent recommends wearing
grounding wrist or foot straps. Failure to do so may result in damage to the
computer.
