User`s guide

Setting Up the Oscilloscope
To inspect options and accessories
1-10
Acquisition memory upgrades are available to protect your Infiniium
oscilloscope investment when acquisition memory needs change. You can
install memory upgrades without opening the oscilloscope case or requiring on-
site service. Acquisition memory upgrades are listed in table 1-3.
Table 1-3
Acquisition memory upgrades for Infiniium Oscilloscopes
Agilent Model
Number
Description
N5404A Infiniium 80000B Series Oscilloscopes
2 MPts (half channel mode)
1 MPts (full channel mode)
64 MPts (half channel mode, 4 GSa/s)
32 MPts (half channel mode, ≤ 2 GSa/s)
N5407A Infiniium 8000A Series Oscilloscopes
Option 040 — 8 MPts (half channel mode), 4 MPts (full channel mode)
Option 080 — 16 MPts (half channel mode), 8 MPts (full channel mode)
Option 160 — 32 MPts (half channel mode), 16 MPts (full channel mode)
Option 320 — 64 MPts (half channel mode), 32 MPts (full channel mode)
Option 640 — 128 MPts (half channel mode), 64 MPts (full channel mode)
