Agilent Technologies E4418B Options
Agilent E4418B User’s Guide xi
Agilent Technologies E4418B Options
The Agilent E4418B power meters have the following options available:
• Option 001, supplies an internal rechargeable battery providing
full instrument functionality when access to an ac power outlet is
not available.
• Option 002, supplies parallel rear panel sensor input(s). The
power reference oscillator output is on the front panel.
• Option 003, supplies parallel rear panel sensor input(s). The
power reference oscillator output is also on the rear panel.
• Option 004, deletes the Agilent 11730A sensor cable(s) provided.
• Option 0BO, deletes manual set.
• Option 908, provides rackmount kit for one instrument.
• Option 909, provides rackmount kit for two instruments.
• Option 915, provides the Agilent E4418B/E4419B Service Guide.
• Option 916, provides an additional Agilent E4418B User’s Guide
and Agilent E4418B/E4419B Programming Guide.
• Option 1BN, provides MIL-STD 45662A, Certificate of
Calibration.
• Option 1BP, provides MIL-STD-45662A, Certificate of Calibration
and data.
Available Accessories
• Agilent 34161A Accessory Pouch
• Agilent 34141A Yellow soft carry/operating case
• Agilent 34131A basic instrument transit case
• Agilent E9287A Spare battery pack - for instruments fitted with
option 001 only
• Agilent 34397A 12 Vdc to 115 Vac inverter (Option 0E3 230 V)
• The following Agilent power sensor cables are available:
■ Agilent 11730A 1.5 m (7.5 ft)
■ Agilent 11730B 3 m (10 ft)
■ Agilent 11730C 6.1 m (20 ft)
■ Agilent 11730D 15.2 m (50 ft)
■ Agilent 11730E 30.5 m (100 ft)
■ Agilent 11730F 61 m (200 ft)
