Getting Started
The Display Layout
Agilent E4418B User’s Guide 1-9
current measurement.
For example, the display shows:
50MHz
(10,C)
This is equivalent to reference number 4 in Table 1-1 and when
looked up in Table 1-2 shows that:
• the sensor type is 8480 series
• a sensor calibration table is selected (10)
• a frequency dependent offset table is selected(C).
Table 1-1
Reference
Number
Upper
Display Line
Lower
Display Line
1
CF:xxx.x%
2
CF:xxx.x% xxx.xyHz(a)
3
xxx.xyHz (nn)
4
xxx.xyHz (nn,a)
5
xxx.xyHz
6
xxx.xyHz (a)
Where “y” is the frequency multiplier (M or G), “nn” is the
sensor calibration table number and “a” is the frequency
dependent offset table letter.
