Getting Started
The Display Layout
1-10 Agilent E4418B User’s Guide
Table 1-2
Reference
Number
Sensor
Series
Sensor
Correction
Frequency Dependent
Offset Correction
1
8480
Series
Sensors
Directly entered
Calibration Factor
None
2
From offset table
3
Frequency dependent
- from selected sensor
calibration table
None
4
From offset table
5
E-Series
Sensors
Frequency dependent
- downloaded directly
from sensor
None
6
From offset table
