2-2
Preparing the Oscilloscope for Use
To prepare your oscilloscope for use, you need to do the following tasks.
After y ou have completed them, you will be ready to use the oscil loscope.
In the following topics you will:
• adjust the handle
• power-on the oscilloscope
• adjust the display intensity
• connect the oscilloscope probes
• connect the digital probes (with 54621D and 54622D)
• connect a printer
• connect a RS-232 cable
• verify basic oscilloscope operation
• get started using the oscilloscope interface
• learn how to use Quick Help
This chapter also tells you how to:
• clean the oscilloscope
