Chapter 13 223
SCPI Command Reference
E5061A/E5062A commands
13. SCPI Command
Reference
:CALC{1-4}:FUNC:DOM:COUP
Syntax :CALCulate{[1]|2|3|4}[:SELected]:FUNCtion:DOMain:COUPle {ON|OFF|1|0}
:CALCulate{[1]|2|3|4}[:SELected]:FUNCtion:DOMain:COUPle?
Description For channel 1 (:CALC1) to channel 4 (:CALC4), specifies whether to set the coupling of
the analysis range of the :CALC{1-4}:FUNC:EXEC command for all traces.
Parameters
Query response {1|0}<newline><^END>
Example of use
10 OUTPUT 717;":CALC1:FUNC:DOM:COUP OFF"
20 OUTPUT 717;":CALC1:FUNC:DOM:COUP?"
30 ENTER 717;A
Related commands :CALC{1-4}:FUNC:EXEC on page 225
Equivalent key No equivalent key is available on the front panel.
Description
ON or 1 (preset value) Specifies the analysis range with the trace coupling.
OFF or 0 Specifies the analysis range for each trace.
