1 Introduction
Your Multimeter in Brief
18 U1231A/U1232A/U1233A User’s Guide
Rear panel
The rear panel parts of your multimeter are described in
this section. Click the respective “Learn more” pages in
Table 1- 4 for more information on each part.
Figure 1-8 Rear panel
Table 1 - 4 Rear panel parts
Legend Description Learn more on:
1 IR communication port page 11
2 Tilt stand page 11
3 Battery and fuse access cover page 3
4 Flashlight page 7
1
3
4
2
