Available channels
Channels received by SoloDL connected to Get GP1 EVO and Get Power ECUs changes according to
the protocol (ECU Model) you set in Race Studio 2 configuration.
3.1
Channel received from GET “GET GP1_EVO” protocol
Channels received by SoloDL connected to GET "GP1_EVO" protocol are:
ID CHANNEL NAME FUNCTION
ECU_1 ECU_RPM RPM
ECU_2 ECU_TPS Throttle position
ECU_3 ECU_MAP Manifold air pressure
ECU_4 ECU_TH2O Engine coolant temperature
ECU_5 ECU_TAIR Intake air temperature
ECU_6 ECU_TOIL Oil temperature
ECU_7 ECU_VBB1 Battery supply 1
ECU_8 ECU_VBB2 Battery supply 2
ECU_9 ECU_BARO Barometric pressure
ECU_10 ECU_LAMBDA1AVG Lambda 1 Average value
ECU_11 ECU_LAMBDA1RAW Lambda 1 raw value
ECU_12 ECU_KLAMBDA1 Lambda 1 correction
ECU_13 ECU_INJ_TIME Injection time
ECU_14 ECU_SPARK_1 Spark angle 1
ECU_15 ECU_PHASE ECU phase
ECU_16 ECU_SPEED1 Speed 1
ECU_17 ECU_SPEED2 Speed 2
ECU_18 ECU_MAPPA Selected map
