ECU_19 ECU_GEAR Engaged gear
ECU_20 ECU_DTPS Throttle position derivative
ECU_21 ECU_DECAYINJ Differential injection revs 1
ECU_22 ECU_CINJ_DFARF Throttle derivative control during injection time
ECU_23 ECU_KINJTH2O Water temperature correction during injection time
ECU_24 ECU_KINJTAIR Air temperature correction during injection time
ECU_25 ECU_REVS ECU revolutions in counts
3.2
Channel received from GET “A4” protocol
Channels received by SoloDL connected to GET "A4" protocol are:
ID CHANNEL NAME FUNCTION
ECU_1 ECU_RPM RPM
ECU_2 ECU_REV Engine revolution counter
ECU_3 ECU_THROTTLE Throttle position sensor %
ECU_4 ECU_MAN_PRESS Manifold air pressure
ECU_5 ECU_ENG_TMP Engine temperature
ECU_6 ECU_INT_TMP Intake air temperature
ECU_7 ECU_VBB Battery supply
ECU_8 ECU_BARO_PRES Barometric pressure
ECU_9 ECU_GEAR_CUT Gear cut
ECU_10 ECU_GEAR Engaged gear
ECU_11 ECU_SPEED1 Speed 1
ECU_12 ECU_SPEED2 Speed 2
ECU_13 ECU_LAMB_AVG Lambda Average value
ECU_14 ECU_LAMB_RAW Lambda raw value
ECU_15 ECU_FORK Fork damper value
ECU_16 ECU_SHOCK Shock damper value
ECU_17 ECU_AD_PEDAL Pedal analog value
