User's Manual

5
6
Speaker Illustraon
1. Volume control/input selecon
Volume control
Rotate clockwise to increase volume; rotate
counter clockwise to reduce volume.
When reaching maximum volume level,
connue to rotate volume control will not
change volume.
Input selecon
Press to switch between BAL – AUX – USB
– Opcal – Coaxial – Bluetooth modes.
(As DSP will be reconfigured when input
mode is switched, it is recommended to
press aer the current mode indicator
flashes once.)
Standby control
Press and hold to alternate between Power
on and Stand by mode.
2. Bass level adjustment
Room acouscs may dictate which type of
adjustment you need to make to retain the
proper frequency response from the speaker.
Turn from “0” to le to reduce low frequencies;
Turn from “0” to right to increase low
frequencies.
3. Treble level adjustment
Room acouscs may dictate which type of
adjustment you need to make to retain the
proper frequency response from the speaker.
Turn from “0” to le to reduce high frequencies;
Turn from “0” to right to increase high frequencies.
4. Balanced input port
Connect to audio source devices with
balanced output using XLR cable.
5. Power switch
Turn on/off speaker power.
6. AC input socket
Connect to plug of power cord.
7. Auxiliary input port
Connect to audio source devices with RCA
output port using RCA audio cable.
8. USB B type port
Connect to audio source devices with USB
output port using USB connecng cable.
9. Opcal input port
Connect to audio source devices with opcal
output port using fiber opc input audio
cable.
10. Coaxial input port
Connect to audio source devices with
coaxial output port using coaxial cable.
11. Passive speaker connector
Connect to passive speaker using speaker
connecng cable.
12. Acve speaker connector
Connect to acve speaker using speaker
connecng cable.
13. LED indicator/remote control receiving
window
Indicates current input mode based on
audio sources and input selecon.
②
①
④
⑤
6
③
7
8
9
10
O
I
A 30 0
AC TIVE SPE AK ER SYST EM
11
13
Box Contents
Speaker connecng cable
Fiber opc input audio cable
RCA to 3.5mm jack plug
Remote control
Acve speaker
Passive speaker
RCA audio cable
Power cable
USB connecng cable
12
IN PU T
B AS S
TR EB LE
/
VO LU M E
L SPEAK ER OUT
BALAN CED IN
OFF ON
100- 240V~ 50/60 Hz 800m A
POWER
AC~IN PUT
L
R
User manual
Note: Bass and Treble trimmers are automacally bypassed in default when system is taking
signal from balanced input ports, thus to avoid changes to the input signal.
English English
