OPERATING INSTRUCTIONS INSTRUCCIONES DE MANEJO MODE D’EMPLOI CSD-FD89 CSD-FD79 CSD-FD77 CD STEREO RADIO CASSETTE RECORDER RADIOCASETE ESTÉREO CON REPRODUCTOR DE DISCOS COMPACTOS RADIO-CASSETTE LECTEUR DE CD STEREO English : See page 2. 8C-CHE-903-11 020201BCK-I-FM En Español : Ver la página 12. E Français : Voir page 22.
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN “CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.” IMPORTANT SAFETY Read the Operating Instructions carefully and completely before operating the unit. Be sure to keep the Operating Instructions for future reference.
INSTRUCTIONS Object and Liquid Entry – Never push objects of any kind into this unit through the cabinet slots as they may touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit. Electric Power Power Sources – This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company.
Power supply Using on batteries Open the lid of the battery compartment on the rear and insert eight R14 (size C) batteries, not supplied, as illustrated below. Then close the lid. To switch from AC power supply to battery supply, disconnect the AC cord from the AC inlet. OPE/BATT The OPE/BATT indicator lights up while the power is on. R14 (C) Using on AC house current Connect the AC cord as illustrated below.
Remote control (CSD-FD89/79 only) Specifications Insert two R6 (size AA) batteries. Tuner section Frequency range, antenna – FM: 87.5 - 108.0 MHz Rod antenna, AM: 530/531 - 1,710/1,602 kHz (10/9 kHz step) Ferrite bar antenna Deck section R6 (AA) When the reach of the remote control signal is less than 5 meters (16 feet), replace the batteries.
\PHONES RADIO BAND s STOP/SET/CLEAR REPEAT/MODE/ SLEEP POWER 6STANDBY/ ON e PLAY/PAUSE T-BASS VOLUME 3-MODE EQ f, g (TUNING -, +) PRESET A 1 TUNER OPERATION Press RADIO BAND * repeatedly to select the desired band. FM AM The power is turned on and the previously tuned station is received. * or BAND on the remote control (applicable when the AC cord is connected, CSD-FD89/79 only) 2 Press f, g (TUNING -, +) to select a station. During FM stereo reception, is displayed.
DISPLAY 0-9, +10 SOUND ADJUSTMENT MODE Volume or tone adjustment does not affect recording. EQ VOL k, i BAND e PLAY/ PAUSE f, g s STOP (CSD-FD89/79 only) VOLUME (VOL, CSD-FD89/79 only) Turn VOLUME on the unit or press VOL i or k on the remote control. The volume level is displayed as a number from 0 to 25. • The volume level is automatically set to 14 if the power is turned off when the volume level is set to 15 or more.
POWER 6STANDBY/ ON REPEAT/MODE/ SLEEP s STOP/SET/CLEAR CD e PLAY/PAUSE f, g B 1 CD OPERATION Press CD. The power is turned on. 2 Press PUSH OPEN to open the disc compartment. Place a disc with the printed side up and close the disc compartment. PUSH OPEN To select a track directly with the remote control (CSD-FD89/79 only), press the numbered buttons 0-9 and +10. CD play starts from the selected track and continues to the last track. Example: To select number 25, press +10, +10 and 5.
0-9, +10 REPEAT e PLAY/PAUSE f, g s STOP (CSD-FD89/79 only) PROGRAMMED PLAY Up to 30 tracks can be programmed from the disc. 1 In stop mode, hold down s STOP/SET/ CLEAR * until “M” flashes in the display. The program number, “P-01” is also displayed. * or s STOP on the remote control (CSD-FD89/79 only) 2 Press f or g to select a track, then press s to store it.
s STOP/SET/CLEAR REPEAT/MODE/ SLEEP POWER 6STANDBY/ ON e PLAY/PAUSE TAPE f, g w REC C TAPE OPERATION • Use Type I (normal) tapes only. • The unit plays (records on) the side facing up. PLAYBACK 1 Press TAPE. The power is turned on. 2 Press PUSH EJECT to open the cassette holder and insert a tape with the side to be played facing up and the exposed side facing forward. RECORDING 1 Insert a tape with the side to be recorded on facing up and the exposed side facing forward.
SETTING THE SLEEP TIMER MODE e PLAY/ PAUSE The unit can be turned off automatically at a specified time. 1 w REC * or MODE on the remote control (CSD-FD89/ 79 only) f, g s STOP (CSD-FD89/79 only) Hold down REPEAT/MODE/SLEEP * until “SLEEP” flashes in the display. 2 Within 4 seconds, press f or g to specify the time until the power is turned off. Each time it is pressed, the time changes between 10 and 180 minutes in 10-minute steps. Specified time While the sleep timer works, “SLEEP” is displayed.
ADVERTENCIA PARA REDUCIR EL RIESGO DE INCENDIOS O SACUDIDAS ELECTRICAS, NO EXPONGA ESTE APARATO A LA LLUVIA NI A LA HUMEDAD. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN “CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.” INSTRUCCIONES Lea cuidadosa y completamente el manual de instrucciones antes de utilizar la unidad.
IMPORTANTES DE SEGURIDAD (Esta unidad no deberá colocarse nunca cerca ni sobre un aparato o salida de calefacción.) Esta unidad no deberá colocarse en una instalación empotrada, como una librería, a menos que la ventilación sea adecuada. Entrada de objetos sólidos y líquidos – No introduzca objetos de ningún tipo en la unidad a través de las ranuras de la caja ya que podrían tocar puntos con tensión peligrosa o provocar cortocircuitos, lo que podría resultar en descargas eléctricas o incendios.
Alimentación Uso con pilas OPE/BATT El indicador OPE/BATT se enciende cuando el aparato está encendido. Abrir la tapa del compartimiento de las pilas situada en la parte trasera e insertar ocho pilas R14 (tamaño C), no incluidas, como se ilustra abajo. Luego cerrar la tapa. Desconectar el cable de alimentación de la toma de alimentación para conmutar entre alimentación de CA y a pilas. Uso a corriente alterna de la red Conectar el cable de alimentación con se ilustra abajo.
Control remoto Especificaciones (CSD-FD89/79 solamente) Sección del sintonizador Gama de frecuencias, antena – FM: 87,5 - 108,0 MHz, antena de varilla. AM: 530/531 - 1.710/1.602 kHz (pasos de 10/9 kHz), antena de barra de ferrita. Insertar dos pilas R6 (tamaño AA). Sección de la platina R6 (AA) Cambiar las pilas cuando la distancia de funcionamiento del control remoto sea inferior a 5 metros.
\PHONES RADIO BAND s STOP/SET/CLEAR REPEAT/MODE/ SLEEP POWER 6STANDBY/ ON e PLAY/PAUSE T-BASS VOLUME 3-MODE EQ f, g (TUNING -, +) PRESET A 1 FUNCIONAMIENTO DEL SINTONIZADOR Pulsar repetidamente RADIO BAND * para seleccionar la banda deseada. FM AM Se enciende el aparato y se sintoniza la emisora que estaba sintonizada en el momento de apagarlo previamente. * o BAND en el control remoto (cuando está conectado el cable de alimentación, CSDFD89/79 solamente).
DISPLAY BAND e PLAY/ PAUSE 0-9, +10 AJUSTE DEL SONIDO MODE Los ajustes del volumen y los tonos no afectan a la grabación. EQ VOL k, i VOLUME (VOL, CSD-FD89/79 solamente) f, g s STOP (CSD-FD89/79 solamente) Gire VOLUME en el aparato o presione VOL i o k en el control remoto. El nivel de volumen se presenta como un número desde el 0 al 25. • Cuando se apaga el aparato el nivel del volumen se ajusta automáticamente en 14 si se ajustó en 15 ó más.
POWER 6STANDBY/ ON REPEAT/MODE/ SLEEP s STOP/SET/CLEAR CD e PLAY/PAUSE f, g B 1 MANEJO DEL CD Pulsar CD. Se enciende el aparato. 2 Pulsar PUSH OPEN para abrir el compartimiento del disco. Colocar un disco con el lado impreso hacia arriba y cerrar el compartimiento. PUSH OPEN Para seleccionar directamente una pista con el control remoto (CSD-FD89/79 solamente), pulsar los botones numéricos 0-9 y +10. El CD empieza a reproducirse desde la pista seleccionada y continúa hasta el final del disco.
0-9, +10 REPEAT e PLAY/PAUSE f, g s STOP (CSD-FD89/79 solamente) REPRODUCCIÓN PROGRAMADA Se puede programar la reproducción de hasta 30 pistas de un disco. 1 En la modalidad de parada, mantenga oprimido s STOP/SET/CLEAR * hasta que “M” parpadee en la pantalla. También se presenta el número de programa “P-01”. * o s STOP en el control remoto (CSD-FD89/79 solamente). 2 Oprima f o g para seleccionar una pista, y luego oprima s para almacenarla en memoria.
s STOP/SET/CLEAR REPEAT/MODE/ SLEEP POWER 6STANDBY/ ON e PLAY/PAUSE TAPE f, g w REC C MANEJO DE LA PLATINA • Utilizar solamente cintas de tipo I (normales). • El aparato reproduce (graba) en el lado encarado hacia arriba. REPRODUCCIÓN 1 Presione TAPE. Se enciende el aparato. 2 Presione PUSH EJECT para abrir el compartimiento de la casete e inserte una cinta con el lado que se va a reproducir encarado hacia arriba y el lado donde la cinta queda expuesta encarado hacia adelante.
AJUSTE DEL TEMPORIZADOR DE DESCONEXIÓN MODE e PLAY/ PAUSE w REC El aparato puede apagarse automáticamente a una hora designada. 1 f, g * o MODE en el control remoto (CSD-FD89/79 solamente). s STOP 2 (CSD-FD89/79 solamente) Para dejar de grabar, presione s. Para hacer una pausa durante la grabación (solamente cuando la fuente sea RADIO), oprima e. Durante la modalidad de pausa en grabación parpadea “REC” lentamente. Para reanudar la función, vuelva a oprimirlo.
AVERTISSEMENT POUR REDUIRE LE RISQUE D’INCENDIE OU DE CHOC ELECTRIQUE, NE PAS EXPOSER CET APPAREIL A LA PLUIE OU A L’HUMIDITE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN “CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.” INSTRUCTIONS IMPORTANTES Lisez attentivement et entièrement le Mode d’emploi avant de faire fonctionner l’appareil. Conservez-le bien pour toute référence ultérieure.
CONCERNANT LA SECURITE Pénétration d’objets et de liquides – Ne poussez jamais d’objets de quelque nature qu’ils soient dans les fentes de l’appareil. Ils pourraient toucher des emplacements à tension dangereuse ou court-circuiter des pièces, ce qui pourrait provoquer un incendie ou une décharge électrique. Ne répandez jamais de liquide quel qu’il soit sur l’appareil.
Alimentation Alimentation sur piles OPE/BATT L’indicateur OPE/BATT s’allume lorsque l’appareil est sous tension. Ouvrir le couvercle du logement des piles au dos de l’appareil et insérer huit piles R14 (taille C), non fournies, comme indiqué ci-dessous. Puis, refermer le couvercle. Pour passer de l’alimentation sur secteur à l’alimentation sur piles, débrancher le cordon secteur de la prise secteur. Alimentation sur le secteur Raccorder le cordon secteur comme indiqué cidessous.
Télécommande Spécifications (modèle CSD-FD89/79 seulement) Section tuner Plage de fréquence, antenne – FM : 87,5 MHz - 108,0 MHz, antenne à tige. AM : 530/531 kHz - 1.710/1.602 kHz (pas de 10/9 kHz), antenne à barre de ferrite. Insérer deux piles R6 (taille AA). Section magnétocassette R6 (AA) Quand la portée du signal de télécommande est inférieure à 5 mètres, remplacer les piles.
\PHONES RADIO BAND s STOP/SET/CLEAR REPEAT/MODE/ SLEEP POWER 6STANDBY/ ON e PLAY/PAUSE T-BASS VOLUME 3-MODE EQ f, g (TUNING -, +) PRESET A 1 FONCTIONNEMENT DU TUNER Appuyer de façon répétée sur RADIO BAND * pour sélectionner la gamme. FM AM L’appareil se met sous tension et la station préalablement accordée est reçue. * ou BAND sur la télécommande (applicable lorsque le cordon secteur est raccordé, modèle CSD-FD89/79 seulement). 2 Appuyer sur f, g (TUNING -, +) pour sélectionner la station.
DISPLAY BAND e PLAY/ PAUSE 0-9, +10 RÉGLAGE DE LA TONALITÉ MODE Les réglages du volume et de la tonalité sont sans effet sur l’enregistrement. EQ VOL k, i VOLUME (VOL, modèle CSD-FD89/79 seulement) f, g s STOP (modèle CSD-FD89/79 seulement) PRÉRÉGLAGE DES STATIONS L’appareil peut mémoriser un total de 15 stations pour chaque gamme. 1 2 Sélectionner la station. Appuyer une fois sur s STOP/SET/ CLEAR * de façon que “M” s’affiche pour mémoriser la station.
POWER 6STANDBY/ ON REPEAT/MODE/ SLEEP s STOP/SET/CLEAR CD e PLAY/PAUSE f, g B 1 FONCTIONNEMENT DU DISQUE COMPACT Appuyer sur CD. L’appareil se met sous tension. 2 Appuyer sur PUSH OPEN pour ouvrir le tiroir du disque. Mettre un disque avec la face imprimée orientée vers le haut et refermer le tiroir du disque. Pour sélectionner une plage directement avec la télécommande (modèle CSD-FD89/79 seulement), appuyer sur les touches numériques 0-9 et +10.
0-9, +10 REPEAT e PLAY/PAUSE f, g s STOP (modèle CSD-FD89/79 seulement) LECTURE PROGRAMMÉE Il est possible de programmer un maximum de 30 plages du disque. 1 En mode d’arrêt, maintenir s STOP/SET/ CLEAR * enfoncé jusqu’à ce que “M” clignote sur l’affichage. Le numéro du programme, “P-01” s’affiche également. * ou s STOP sur la télécommande (modèle CSDFD89/79 seulement). 2 Appuyer sur f ou g pour sélectionner la plage, puis appuyer sur s pour la mémoriser.
s STOP/SET/CLEAR REPEAT/MODE/ SLEEP POWER 6STANDBY/ ON e PLAY/PAUSE TAPE f, g w REC C FONCTIONNEMENT DE LA CASSETTE • Utiliser uniquement des cassettes de type I (normales). • L’appareil lit (enregistre) la face orientée vers le haut. LECTURE 1 Appuyer sur TAPE. s STOP/SET/CLEAR * – Arrête la lecture. * ou s STOP sur la télécommande (modèle CSDFD89/79 seulement). e PLAY/PAUSE – Arrête temporairement la lecture. Pendant le mode de pause, le compteur de bande clignote.
RÉGLAGE DE LA MINUTERIE DE SOMMEIL MODE e PLAY/ PAUSE w REC Il est possible de mettre automatiquement l’appareil hors tension à une heure spécifiée. 1 f, g * ou MODE sur la télécommande (modèle CSD-FD89/79 seulement). s STOP (modèle CSD-FD89/79 seulement) Pour arrêter l’enregistrement, appuyer sur s. Pour effectuer une pause d’enregistrement (seulement si la source est RADIO), appuyer sur e. Pendant le mode de pause d’enregistrement, “REC” clignote lentement.
NOTE REMARQUE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
