GEBRUIKSAANWIJZING OPERATING INSTRUCTIONS BEDIENUNGSANLEITUNG ALD2216FH KLEURENTELEVISIE MET AFSTANDSBEDIENING COLOUR TELEVISION WITH REMOTE CONTROL FARBFERNSEHGERÄT MIT FERNBEDIENUNG
Contents Accessories .......................................................... 33 Features ............................................................... 33 Preparation ........................................................... 34 Safety Precautions ............................................... 34 Power Source ................................................... 34 Power Cord ....................................................... 34 Moisture and Water ..........................................
Please read the corresponding instructions of this handbook prior to the first usage of the device, even when the usage of electronic devices is familiar to you. Notice especially the chapter SAFETY PRECAUTIONS. Carefully keep the handbook as future reference. When selling the device or giving it away, absolutely give these direction for use. Accessories INFO SLEEP SCREEN SOURCE PRESETS MENU RETURN Batteries: 2 X AAA FAV LANG. SUBTITLE EPG / Features • Remote controlled colour LCD TV.
Preparation Cleaning For ventilation, leave a free space of at least 10 cm all around the set. To prevent any fault and unsafe situations, please do not place any objects on top of the set. Before cleaning, unplug the TV set from the wall outlet. Do not use liquid or aerosol cleaners. Use soft and dry cloth. Use this device in moderate climates. The slots and openings on the TV set are intended for ventilation and to ensure reliable operation.
Information for Users in European Union Countries This symbol on the product or on its packaging means that your electrical and electronic device should be disposed at the end of its service life separately from your household wastes. There are separate collection systems for recycling in EU. power cord should principally be separated from the mains socket prior to a longer period of non-usage, i.e. during vacations.
Overview of the Remote Control 1. Standby 2. Image size INFO 3. Sleep timer 4. Numeric buttons 5. Return / TXT Index SLEEP SCREEN SOURCE PRESETS 6. Cursor up / TXT up page 7. Cursor left 8. Programme up 9. Programme down 10. Mono-Stereo / Dual I-II 11. Swap 12. No function 13. Info / TXT reveal RETURN MENU 14. Picture mode selection 15. Source selection 16. Red / Sound 17. Green / Picture 18. Yellow / Feature 19. Menu 20. Blue / Install 21. OK /Select 22. Cursor righ / TXT Subpage 23.
LCD TV and Operating Buttons FRONT and REAR VIEW SIDE VIEW Control Buttons 1. Up button 2. Down button 3. Programme/Volume / AV selection button 4. Standby/On button Note:You can use “+/-” buttons to change volume. If you want to change channels, press P/V/AV button once and then use “+/-” buttons. If you hold the P/V/AV button about a few seconds, source OSD will be displayed. Main menu OSD cannot be displayed via control buttons. Viewing the Connections- Back Connectors HDMI 1.
Viewing the Connections - Side Connectors 1. Video Input is used for connecting video signals of external devices.Connect the video cable between the VIDEO IN socket on the TV and the VIDEO OUT jack on your device. 2. Audio Inputs are used for connecting audio signals of external devices. Connect the audio cable between the AUDIO INPUTS on the TV and the AUDIO OUTPUT jacks on your device.
Connecting the LCD TV to a PC For displaying your computer’s screen image on your LCD TV, you can connect your computer to the TV set. • Power off both computer and display before making any connections. • Use 15-pin D-sub display cable to connect a PC to the LCD TV.Use an audio cable between audio inputs of the TV (side) and audio output of your PC to enable sound connection. • When the connection is made, switch to PC source. See “Input selection” section.
Using Side AV Connectors You can connect a range of optional equipment to your LCD TV. Possible connections are shown below. Note that cables shown in the illustration are not supplied. • For connecting a camcorder, connect to the VIDEO IN socket and the AUDIO SOCKETS. For selecting the related source, see the section “Input selection” in the following parts.
First Time Installation When the TV set is operated for the first time, the following menu screen will be displayed: Note : YPbPr mode can be use only when you connect a device that has a YPbPr output through the PC input with YPbPr to PC cable (YPbPr cable is not supplied). Select your Country, Language and Text language by using “ ” or “ ” and “ ” or “ ” buttons. Press OK or RED button to continue. To cancel, press the BLUE button.
Programme Selection (Direct Access) Film Mode • Press numeric buttons on the remote control to select programmes between 0 and 9. The TV will switch to the selected programme. To select programmes between 10-199 (for analogue), press the numeric buttons consecutively • Press directly the programme number to reselect single digit programmes Films are recorded at a different number of frames per second to normal television programmes. Analogue TV Menu System Press “ ” or “ ” button to select Film Mode.
Store Press “ ” or “ ” button to select Store. Press “ ” or OK button to store the settings. “Stored...” will be displayed on the screen. Feature Menu Press “ ” or “ ” button to change the preset. In equalizer menu, the preset can be changed to Flat, Classic, User, Music, Movie and Speech. Select the desired frequency by pressing “ ” or “ ” button and increase or decrease the frequency gain by pressing “ ” or “ ” button. Press the “MENU” button to return to the previous menu.
By pressing “ ” or “ ” button, select Blue Background. Press “ ” or “ ” button to set Blue Background as On or Off. Menu Background Press “ ” or “ ” button to select Menu Background. You can set menu background level by pressing “ ” or “ ” button. Menu Timeout To set a specific display timeout for menu screens, set a value for this option. Press “ ” or “ ” button to select Menu Timeout. Use “ ” or “ ” button to change menu timeout to 15 sec, 30 sec or 60 sec.
Colour System Press “ ” or “ ” button to select Colour System. Use “ ” or “ ” button to change the colour system to AUTO, PAL, SECAM, PAL60, NTSC 4,43 or NTSC 3,58. Store Press “ ” or “ ” button to select Store. Press “ ” or “OK” button to store the settings. “Stored...” will be displayed on the screen. Program Table Select Program Table by pressing “ ” or “ Press “ ” to display Program Table: button. Press “ ” or “ ” button to select your country. If you want to exit from A.P.S.
Dot Clock PC Mode Menu System See “Connecting the LCD TV to a PC” section for connecting a PC to the TV set. For switching to PC source, press “SOURCE” button on your remote control and select PC input. You can also use “Source” menu to switch to PC mode. Note that PC mode menu settings are available only while the TV is in PC source. Dot Clock adjustments correct the interference that appear as vertical banding in dot intensive presentations like spreadsheets or paragraphs or text in smaller fonts.
Cinema Zoom Modes You can change the aspect ratio (image size) of the TV for viewing the picture in different zoom modes. This zooms up the wide picture (16:9 aspect ratio) to the full screen. Press “SCREEN” button to directly change the zoom mode. Available zoom modes are listed below. Note: Subtitle In YPbPr and HDMI modes, while in 720p-1080i resolutions, only 16:9 mode is available. This zooms up the wide picture (16:9 aspect ratio) with subtitles to the full screen.
Teletext Tips Teletext system transmits information such as news, Image Persistence sports and weather on your TV. Note that if the signal degrades, for example in poor/adverse weather conditions, some text errors may occur or the teletext mode may be aborted. Teletext function buttons are listed below: Please note that ghosting may occur while displaying a persistent image. LCD TVs’ image persistence may disappear after a short time. Try turning off the TV for a while.
Appendix A: PC Input Typical Display Modes The display has a maximum resolution of 1600 X 1200. The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen. Resolution Index Frequency Hor Ver Ver (Hz) Hor (KHz) Standard 1 640 480 60 31.5 VESA 2 640 480 72 37.9 VESA 3 640 480 75 37.
Appendix B: AV and HDMI Signal Compatibility (Input Signal Types) Source EXT-1 (SCART) FAV YPbPr HDMI Supported Signals Available PAL 50/60 O NTSC 60 O RGB 50 O RGB 60 O PAL 50/60 O NTSC 60 O 480I 60Hz O 480P 60Hz O 576I 50Hz O 576P 50Hz O 720P 50Hz O 720P 60Hz O 1080I 50Hz O 1080I 60Hz O 1080P 50Hz O 1080P 60Hz O 480I 60Hz O 480P 60Hz O 576I 50Hz O 576P 50Hz O 720P 50Hz O 720P 60Hz O 1080I 50Hz O 1080I 60Hz O 1080P 24Hz O 1080P 25
Specifications TV BROADCASTING PAL/SECAM B/G D/K K’ I/I’ L/L’ RECEIVING CHANNELS VHF (BAND I/III) UHF (BAND U) HYPERBAND NUMBER OF PRESET CHANNELS 200 CHANNEL INDICATOR On Screen Display RF AERIAL INPUT 75 Ohm (unbalanced) OPERATING VOLTAGE 220-240V AC, 50 Hz. AUDIO German+Nicam Stereo AUDIO OUTPUT POWER (WRMS.
Features Contents Features ............................................................... 52 General Properties............................................ 52 Safety Information ................................................ 53 Notes on Discs ..................................................... 53 On handling discs ............................................. 53 On cleaning....................................................... 53 Licence Notification ..............................................
On cleaning Safety Information CAUTION DVD Player is a class 1 laser product. However this product uses a visible laser beam which could cause hazardous radiation exposure. Be sure to operate the player correctly as instructed. • Before playing, clean the disc with a cleaning cloth. Wipe the disc from the center out. CLASS 1 LASER PRODUCT • Manufactured under license from Dolby Laboratories. “Dolby”, and the double-D symbol are trademarks of Dolby Laboratories.
DVD Control Panel Buttons A. Disc loader B. Play / Pause Plays/pauses the disc. When DVD menu (root menu) is active, this button functions as “button select” (selects the highlighted item in menu) if this is not prohibited by the disc. C. Stop / Eject Stop playing disc / Eject or Load the disc Note: • You cannot eject the disc via the remote control. • While playing a file, you should press STOP button three times to eject. Overview of the Remote Control 1. Standby 2. Numeric buttons INFO 3.
General Operation You can operate DVD, movie CD, music or picture CD’s content by using the proper buttons on your remote control. Below are main functions of commonly used remote control buttons. Buttons on the Remote Control DVD Playback Movie Playback Picture Playback Music Playback Play Play Play Play Pause Pause Pause Pause Stop Stop Stop Stop / e/f / / ANGLE C DISPLAY INFO LANG.
11. Reverse stepping is not available. General Playback 12. For your convenience: Basic Play 1. Press on the power button 2. Please insert a disc to the loader. The disc will be automatically loaded and play commences if the disc does not have any menus recorded on it. A menu may appear on the TV screen after a few moments or the film may start immediately after the introduction of the Film Company. This behaviour depends on the disc content and may change.
Preferences Troubleshooting The picture quality is poor (DVD) • Make sure the DVD disc surface is not damaged. (Scratch, fingerprint etc.) • Clean the DVD disc and try again. See instructions described in “Notes on Discs” to clean your disc properly. DEFAULT • Ensure that the DVD disc is in the drawer with the label uppermost. If you choose RESET and press SELECT, the factorypresets are loaded. Parental level and parental password does not change.
No response from remote control Title Number • Make sure the remote control is in the correct mode. • Check batteries are fitted correctly. These numbers are recorded on DVD discs. When a disc contains two or more movies, these movies are numbered as title 1, title 2, etc. • Change the batteries. Track Number If nothing works These numbers are assigned to the tracks, which are recorded on AudioCDs. They enable specific tracks to be located quickly.
Disc Types Compatible with This Unit D is c Ty p e s (L o g o s ) R e c o r d in g Ty p e s D is c S iz e DVD 12 cm A u d io + V id e o A U D IO -C D 8 cm 12 cm M ax. P la y in g T im e S i n g le s id e d ; 2 4 0 m in . C h a r a c t e r is tic s • D V D c o n ta in s e x c e lle n t s o u n d a n d v id e o • V a r io u s s c r e e n a n d a u d io fu n c t io n s c a n b e D o u b le s id e d ; 4 8 0 m in . S i n g le s id e d ; 8 0 m in . D o u b le s id e d ; 1 6 0 m in . 7 4 m in .
Supported File Formats Media File Extension .mpg/ .dat/ .vob Movie (optional) .avi - Music Format Remarks Video Audio (Maximum resolution/Bit rate etc.) MPEG1 MPEG Layer 1/2/3 MPEG2 MPEG2 XviD/ 3ivx PCM/MP3 MPEG4 PCM/MP3 MS ISO MPEG4 PCM/MP3 Support SP and ASP PCM Sample Rate: 8K ~ 48KHz - XviD Verson up to: 1.1.2 / DivX 3.1.x, 4.x, 5.x MPEG 1/2 .
