Adjusting the Sound
To select the listening channel
1.When the disc is stopped, you can press the 5.1/2.1 CH button on the remote control to select different speakers
output status shown on below table.
2.At AV IN function mode, you also can press the
PRO LOGIC II button repeatedly on the remote control to select
PRO LOGIC II (indicator on the front panel of display will illuminate).
3.You can active or off subwoofer output by setup menu.
Notes:
• The wording "2.1 CH" will be corresponded to the audio/sound output from Front Left and Front Right speakers
plus the Subwoofer.
• 5.1/2.1 CH button is no response to JPG CD-ROM or JPG/MP3 CD-ROM. Please select 5.1/2.1 CH output
before putting such CD-ROM.
• Dolby Digital 5.1 CH will not be activated on Pro Logic II.
Pro Logic Emulation Mode (PL II and EMU)
The Pro Logic emulation mode offers users the same robust surround processing as original Pro Logic, in case the source content
is not of optimum quality, or if there is a desire to hear the program more "as it used to be". When this mode is used, it is called Pro
Logic, as before. There is no "Pro Logic I" mode. The Pro Logic emulation mode is optional. Dolby does not require PLII products
to use the original Pro Logic decoding algorithm. However, if the DSP contains the original Pro Logic code, and if the product maker
would like to use it, this is quite acceptable and even encouraged. A product must not offer both original Pro Logic and the Pro Logic
emulation mode.
Manufactured under license from Dolby Laboratories.
'Dolby' , 'Pro Logic' and the double-D symbol are trademarks of Dolby Laboratories.
"DTS" and "DTS Digtial Out" are trademarks of Digital Theater Systems, Inc.
The following table shows which speakers are working in the various modes.
5.1- Represents FRONT LEFT/RIGHT, REAR LEFT/RIGHT, CENTER speakers and SUBWOOFER
2.1- Represents FRONT LEFT/RIGHT speakers and SUBWOOFER
5- Represents FRONT LEFT/RIGHT, REAR LEFT/RIGHT and CENTER speakers
2- Represents FRONT LEFT/RIGHT speakers
EMU MATRIX MUSIC MOVIE BY PASS
SMALL ON 5.1 5.1 5.1 5.1 5.1 or 2.1
LARGE ON 5.1 5.1 5.1 5.1 5.1 or 2
--- OFF 5 5 5 5 5 or 2
SMALL ON 2.1 2.1 2.1 2.1 2.1
LARGE ON 2 2 2 2 2
--- OFF 2 2 2 2 2
5.1 CH --- --- 5.1 5.1 5.1 5.1 5.1
2.1 CH --- ON 2.1 2.1 2.1 2.1 2.1
--- --- OFF 2 2 2 2 2
--- ON 5.1 5.1 5.1 5.1 5.1
--- OFF 5 5 5 5 5
SMALL ON 2.1 2.1 2.1 2.1 2.1
LARGE ON 2 2 2 2 2
--- OFF 2 2 2 2 2
TUNER --- --- --- --- 2.1 2.1 2.1 2.1 2.1
SMALL ON 5.1 5.1 5.1 5.1 5.1
LARGE ON 5.1 5.1 5.1 5.1 5.1
--- OFF 5 5 5 5 5
FUNCTION DISCS
5.1 / 2.1
CH Button
L/R
SPEAKER
(SMALL/
LARGE)
SUB-
WOOFER
ON/OFF
Dolby Pro Logic II Selection
5.1 CH
2.1 CH
DVD MODE
AV_IN ---
DVD /
CD
Dolby Pro
Logic II not
applied on
Tuner, MP3
and PCM
DVD.
---
PCM
DVD
MP 3
2.1 CH
5.1 CH
DTS and DTS Digital Out are trademarks of Digital Theater Systems, Inc.
This Unit does not decode DTS Digital Surround signal.
To enjoy DTS Digital Surround
TM
playback, an external 5.1 channel DTS Digital Surround
TM
decoder system must be
connected to the DIGITAL AUDIO OUT jack of the Main Unit.
